Volkswagen New Beetle. Manual - part 1401





Fig. 140: Scan Tool Display - Coding ECM From M.Y. 2000
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Switch ignition OFF and then ON again.

NOTE:

Entered coding is activated by switching ignition OFF and then ON again. If,
after entering correct code, ignition is NOT switched OFF and ON again,
malfunction: "Control Module incorrectly coded" will become stored in DTC
memory and must be erased.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Erase DTC memory. See DTC MEMORY, CHECKING .

z

Set readiness code. See READINESS CODE, SETTING .

CRUISE CONTROL SYSTEM, CHECKING, ACTIVATING AND DEACTIVATING

Cruise control system, checking

Cruise Control System, apart from control switches, has no components of its own. All functions are provided
by the Fuel injection system.

Special tools

z

VAG1551/1552 Scan Tool using VAG1551/3 Adapter cable

z

VAG1598/22 Test Box (MY 1999)

z

VAG1598/31 Test Box (from MY 2000)

z

Fluke 83 multimeter

z

VW 1594 Adapter kit

z

Wiring diagram

Test sequence

z

Connect VAG1551/1552 Scan Tool. See VAG1551/1552 SCAN TOOL, CONNECTING .

z

Start engine and let idle.

z

Press -0- and -1- buttons to select Address word 01: "Engine electronics"

Display will appear as shown (example only):



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 141: Scan Tool Display - Checking Cruise Control System (1 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press --> button.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 142: Scan Tool Display - Checking Cruise Control System (2 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0- and -8- buttons to select Function 08: "Read measuring value block".

z

Press -Q- button to enter input.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
