Volkswagen New Beetle. Manual - part 1369





Fig. 11: Removing Injection Pump Sprocket Mounting Bolts & Hub Nut
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove tensioning roller nut.

z

Relieve tooth belt tension then remove camshaft and injection pump sprockets.

z

Disconnect Quantity adjuster harness connector and unclip connector from retainer.

z

Remove mounting bolts from assembly bracket -1-.

Fig. 12: Removing Mounting Bolts From Assembly Bracket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove bolt from rear support (arrow).

CAUTION: Do not loosen hub nut -2- for ANY reason. Otherwise, the Diesel injection

pump basic setting will be altered and cannot be reset with normal
workshop equipment.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 13: Removing Bolt From Rear Support
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove Diesel injection pump.

Diesel injection pump, installing

z

Insert injection pump into assembly bracket then tighten mounting bolt on rear support with conical nut
first.

z

Insert front mounting bolts.

z

tighten to 25 Nm (18 ft lb)

z

Install new bolts (arrows) to mount injection pump sprocket to hub but do not tighten.

Fig. 14: Installing New Bolts To Mount Injection Pump Sprocket To Hub
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Align injection pump sprocket to central position in elongated holes.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Lock injection pump sprocket using 3359 pin.

z

Loosen camshaft sprocket mounting bolt a half turn.

z

Place a drift through hole in rear of toothed belt guard and release camshaft sprocket from camshaft taper
with blow from hammer.

Fig. 15: Placing Drift Through Hole In Rear Of Toothed Belt Guard & Releasing Camshaft
Sprocket Using Hammer

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove camshaft sprocket.

z

Check whether TDC mark on flywheel and reference mark are aligned.

z

Place tooth belt on injection pump sprocket and tensioning roller.

z

Install camshaft sprocket into toothed belt and secure sprocket such that the camshaft can still turn.

z

Tension toothed belt using pin wrench (e.g. Matra V159) on eccentric and turning clockwise until notch
and raised mark align (arrows).

Fig. 16: Tensioning Toothed Belt Using Pin Wrench & Aligning Notch & Raised Mark
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 17: Ensuring Retaining Hook Is Correctly Seated In Toothed Belt Guard
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tighten mounting nut.

z

20 Nm (15 ft lb)

z

Check TDC mark on flywheel again.

z

Tighten new mounting bolts for injection pump sprocket.

z

20 Nm (15 ft lb)

z

Tighten camshaft sprocket mounting bolt.

z

45 Nm (33 ft lb)

z

Remove 3359 locking pin.

z

Remove 3418 setting bar from camshaft.

z

Turn crankshaft two rotations in direction of engine rotation until crankshaft is set to cyl. 1 TDC again.

z

Reconnect injection lines, fuel supply line and electrical wiring.

Fill injection pump with Diesel fuel as follows.

z

Screw 1318/10 adapter into injection pump return/supply opening.

z

Connect VAG1390 hand vacuum pump to adapter using approx. 40 inches of transparent plastic hose.

NOTE:

Make sure retaining hook is correctly seated in toothed belt guard.

NOTE:

z

After dynamically checking the injection timing, tighten the bolts an
additional 1/4 turn (90 °).

z

The mounting bolts (stretch design) may only be used once.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
