Volkswagen New Beetle. Manual - part 1333





z

Switch OFF ignition.

z

Disconnect 10-pin Fuel Temperature sensor harness connector (connection to Diesel injection pump
metering control).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 95: Identifying 10-Pin Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Measure resistance between connector terminals 5 + 6.

z

Specification: 0.5 to 2.5 ohm

If specification not obtained:

z

Replace Diesel injection pump. See DIESEL INJECTION PUMP, REMOVING AND
INSTALLING
 .

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING .

If specification obtained:

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.

Fig. 96: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open circuit between Test Box and harness connector using Wiring diagram.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 97: Identifying 10-Pin Harness Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Up to MY 1999

z

Terminal 5 + sockets 2 and 28

z

Terminal 6 + sockets 59, 66 and 80

From MY 2000

z

Terminal 5 + sockets 1 and 2

z

Terminal 6 + sockets 116 and 121

z

Wire resistance: 1.5ohm maximum

z

Check wires for shorting to: one another, Ground and Battery +.

z

Specification: INFINITY ohm

If wiring OK:

z

Replace Engine Control Module -J248-. See Engine Control Module (ECM), replacing .

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING .

Needle Lift Sensor -G80-, checking

The Needle Lift Sensor -G80- signal determines the start of injection. If -G80- fails, start of injection switches
to open-loop control (based on engine speed and load). During normal operation, start of injection is controlled



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



via closed-loop function (based on engine speed, load and temperature).

Special tools

z

VAG1598/22 Test Box (MY 1999)

z

VAG1598/31 Test Box (from MY 2000)

z

Fluke 83 multimeter

z

VW 1594 Adapter kit

z

Wiring diagram

Test sequence

z

Switch OFF ignition.

z

Disconnect Needle Lift Sensor -G80- harness connector. See DIESEL INJECTION SYSTEM,
COMPONENT LOCATIONS OVERVIEW
 .

z

Measure resistance between sensor terminals.

Fig. 98: Identifying Needle Lift Sensor Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Specification: 80 to 120 ohm

If specification not obtained:

z

Replace cyl. 3 fuel injector complete with -G80-. See item 13 .

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
