Volkswagen New Beetle. Manual - part 1313





z

for Automatic transmission

With engine removed

Vehicles with manual transmission

z

Install 2068 A TDC gauge as shown.

z

Set adjustment device to 96 mm (arrow -A-).

z

Left-hand notch of the vernier scale is the reference point.

z

Turn crankshaft until flywheel TDC marking aligns with point of setting device (arrow -B-).

Fig. 8: Setting Adjustment Device & Turning Crankshaft Until Flywheel TDC Marking Aligns
With Setting Device (Manual Transmission)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with automatic transmission

z

Install 2068 A TDC gauge as shown.

z

Set adjustment device to 30 mm (arrow -A-).

z

Left-hand notch of the vernier scale is the reference point.

z

Turn crankshaft until TDC marking on drive plate aligns with point of setting device (arrow -B-).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 9: Setting Adjustment Device & Turning Crankshaft Until Flywheel TDC Marking Aligns With
Setting Device (Automatic Transmission)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

All vehicles

z

Lock camshaft with setting bar.

Fig. 10: Locking Camshaft With Setting Bar 3418
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Centralize setting bar as follows:

Turn camshaft so that one end of setting bar contacts the cylinder head. Using feeler gauge, establish the gap at
the other end of the setting bar. Place a feeler gauge corresponding to half the gap between setting bar and
cylinder head. Turn camshaft until the setting bar contacts the feeler gauge. Place a 2nd feeler gauge, of same
thickness, at the other end between the setting bar and cylinder head.

z

Remove injection pump sprocket mounting bolts -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 11: Removing Injection Pump Sprocket Mounting Bolts & Hub Nut
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove tensioning roller nut.

z

Relieve tooth belt tension then remove camshaft and injection pump sprockets.

z

Disconnect Quantity adjuster harness connector and unclip connector from retainer.

z

Remove mounting bolts from assembly bracket -1-.

Fig. 12: Removing Mounting Bolts From Assembly Bracket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove bolt from rear support (arrow).

CAUTION: Do not loosen hub nut -2- for ANY reason. Otherwise, the Diesel injection

pump basic setting will be altered and cannot be reset with normal
workshop equipment.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 13: Removing Bolt From Rear Support
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove Diesel injection pump.

Diesel injection pump, installing

z

Insert injection pump into assembly bracket then tighten mounting bolt on rear support with conical nut
first.

z

Insert front mounting bolts.

z

tighten to 25 Nm (18 ft lb)

z

Install new bolts (arrows) to mount injection pump sprocket to hub but do not tighten.

Fig. 14: Installing New Bolts To Mount Injection Pump Sprocket To Hub
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Align injection pump sprocket to central position in elongated holes.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
