Fig. 2: Identifying Diesel Injection Pump Components (1.9L ALH)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Intake manifold change-over valve, servicing

The intake manifold change-over flap is closed for approx. 3 seconds when engine stops and then opens again
which reduces the stop jolt.

Intake manifold change-over valve, checking. See CHANGE-OVER VALVE FOR INTAKE MANIFOLD
FLAP -N239-, CHECKING
 .

1. Intake manifold

2. 10 Nm (7 ft lb)

3. O-ring

{

Always replace

4. Connecting flange

z

with EGR valve and change-over flap

5. 10 Nm (7 ft lb)

6. Gasket

{

Always replace

7. Connecting line

z

to exhaust manifold

8. 25 Nm (18 ft lb)

NOTE:

The following list refers to Fig. 3 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



9. Vacuum control element

10. Intake Manifold Flap Change-over valve -N239-

z

Checking. See CHANGE-OVER VALVE FOR INTAKE MANIFOLD FLAP -N239-,
CHECKING
 .

11. Vacuum supply

z

from vacuum pump

Fig. 3: Identifying Intake Manifold Change-Over Valve Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Diesel injection pump, removing and installing

Special tools

z

3098 Lever camber adjustment

z

V159 Pin wrench

z

3359 Rig pin

z

VAG1318/10 Adapter

z

3418 Adjustment guide

z

VAG1390 Hand vacuum pump



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 4: Identifying Special Tools For Removing & Installing Diesel Injection Pump (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Special tools, continued

z

2068A Adj. gauge TDC

z

3035 Injector line wrench

z

VAG1331 Torque wrench 5 to 50 Nm (3.7 to 37 ft lb) or equivalent

Fig. 5: Identifying Special Tools For Removing & Installing Diesel Injection Pump (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Diesel injection pump, removing

WARNING:

Fire hazard! Do NOT have anything in the area that can ignite Diesel fuel.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Unbolt all fuel lines at fuel pump.

z

Cover openings with a clean cloth.

z

Remove connecting line between charge air cooler and intake manifold.

z

Remove upper toothed belt guard and valve cover.

z

Remove vacuum pump for brake servo.

z

Turn crankshaft to cyl. 1 TDC (arrow).

Fig. 6: Turning Crankshaft To Cyl. 1 TDC (Manual Transmission)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn crankshaft to cyl. 1 TDC (arrow)

Fig. 7: Turning Crankshaft To Cyl. 1 TDC (Automatic Transmission)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

Use 3035 tubing wrench to loosen the high pressure fuel lines.
