Fig. 15: Identifying Installation Position Of Mounting Angled side on foot of mounting (arrow) points forward. Exhaust pipe, separation point Fig. 16: Identifying Exhaust Pipe, Separation Point z Cut exhaust pipe at right angles to separating point (arrow -2-). z Position repair clamp -4- when installing (arrows -1- and -3-) z Tightening torque 40 N.m (30 ft lb) Rear muffler, aligning free of stress
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Exhaust System, Emission Controls - 1.9L 4-Cyl. - ALH, New Beetle
|
