Fig. 6: Identifying Installation Position Of Mounting Separating point on exhaust pipe Special tools, equipment, testers, measuring instruments and auxiliary items required z Body saw e.g. V.A.G 1523 Fig. 7: Identifying Separating Point On Exhaust Pipe Work sequence z Separate exhaust pipe at right angles at separating point (arrow -2-). z When installing, position repair double clamp -4- at side markings (arrows -1- and -3-). Tighten torque: Aligning Center Muffler Stress Free
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)
|
