z Tighten screw -11 - to 22 N.m. z Tighten screw -13- to 5 N.m. z Tighten screws -14- and -16- to 22 N.m. Fig. 12: Hand-Tightening Connecting Pipe With Seals, Two Screws And Screw z Install connecting pipe -18- from heat exchanger for exhaust gas recirculation -16- to exhaust manifold - z Tighten bolts and nuts to 22 N.m. Fig. 13: Installing Connecting Pipe From Heat Exchanger For Exhaust Gas Recirculation To EGR VACUUM REGULATOR SOLENOID VALVE -N18-, REMOVING AND INSTALLING Special tools and equipment
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.9L 4-Cyl. - BEW
|
