Volkswagen New Beetle. Manual - part 1273





Fig. 17: Rear Muffler, Aligning Free Stress
Courtesy of VOLKSWAGEN OF AMERICA, INC.

EXHAUST GAS RECIRCULATION (EGR) SYSTEM, OVERVIEW

Exhaust Gas Recirculation (EGR) system components, removing and installing

1. Intake manifold

2. O-ring

z

Replace

3. Throttle valve

z

With EGR valve and control flap

4. Exhaust Gas Recirculation (EGR) valve

z

Component of intake support

z

Can only be replaced with intake support assembly

z

Checking: See EXHAUST GAS RECIRCULATION (EGR) VALVE, CHECKING

NOTE:

Mounting pins on exhaust pipe must run parallel with tunnel bridge (dimension
-x- on left and right = the same).

NOTE:

z

The function/control of the Exhaust Gas Recirculation (EGR) system is
managed by the Diesel Direct Fuel Injection (DFI) Engine Control Module
(ECM) -J248- via the EGR Vacuum Regulator solenoid valve -N18-.

z

The cone shaped plunger in the mechanical EGR valve ensures that
various cross sectional openings are possible at different plunger heights.

z

Every possible valve position is provided via pulsed control.

z

Replace self-locking nuts.

NOTE:

The following list refers to items in Fig. 18 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 1.9L 4-Cyl. - ALH, New Beetle



z

Control, checking:

See Function 03: Output Diagnostic Test Mode, Performing .

5. 10 N.m (7 ft lb)

6. from Air Cleaner

7. Gasket

z

Replace

8. 25 N.m (18 ft lb)

9. Connecting pipe

z

EGR cooler to intake support

10. Connecting pipe

z

EGR cooler to exhaust elbow

11. Exhaust manifold

12. 25 N.m (18 ft lb)

13. to heat exchanger

14. EGR cooler

15. Connection

z

Heater

16. to Coolant expansion tank

Fig. 18: Exploded View Of Exhaust Gas Recirculation (EGR) System Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vacuum hose connections, diagram

1. EGR valve

NOTE:

The following list refers to items in Fig. 19 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 1.9L 4-Cyl. - ALH, New Beetle



2. EGR Vacuum Regulator solenoid valve -N18-

3. Check valve

4. Brake servo

5. Air Cleaner

6. Vacuum pump

Fig. 19: Identifying Vacuum Hose Connections
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Exhaust Gas Recirculation (EGR) valve, checking

Special tools and equipment

z

VAG 1390 Hand vacuum pump

Fig. 20: Identifying VAG 1390 Hand Vacuum Pump
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test sequence



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 1.9L 4-Cyl. - ALH, New Beetle



z

Remove engine cover.

z

Disconnect pipe between Charge Air cooler and intake manifold at intake manifold.

z

Disconnect vacuum hose from EGR valve.

z

Connect VAG 1390 hand vacuum pump to EGR valve.

z

Operate pump and observe membrane rod.

Membrane rod must move in direction of arrow.

Fig. 21: Locating Hand Vacuum Pump Membrane Rod
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect hand vacuum pump hose from EGR valve.

Membrane rod must move back against direction of arrow to its original position.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 1.9L 4-Cyl. - ALH, New Beetle
