From MY 2000 z Terminal 1 + sockets 1 + 2 z Terminal 2 + socket 62 Wire resistance: 1.5 ohms maximum z Check wires for short to one another, to vehicle Ground and to battery Plus. Specification: "INFINITE"ohms If wiring OK z Replace Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM) -J248-: See Engine Control Module (ECM), Replacing . EXHAUST SYSTEM, EMISSION CONTROLS EXHAUST SYSTEM COMPONENTS, REMOVING AND INSTALLING Front exhaust pipe and catalyst with attachments 1. from turbocharger 2. Gasket z Replace 3. 25 N.m (18 ft lb) 4. Catalyst 5. to central muffler 6. Mounting 7. 25 N.m (18 ft lb) NOTE: z Removing and installing exhaust manifold. See TURBOCHARGER z After working on the exhaust system make sure that the system is not z Replace self-locking nuts. NOTE: The following list refers to items in Fig. 12 .
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Exhaust System, Emission Controls - 1.9L 4-Cyl. - ALH, New Beetle
|
