1998-2004 ENGINE Exhaust System, Emission Controls - 1.9L 4-Cyl. - ALH, New Beetle TURBOCHARGER, G-CHARGER CHARGE AIR PRESSURE WITH TURBOCHARGER Turbocharger system components, removing and installing Observe rules for cleanliness. See RULES FOR CLEANLINESS . 1. Exhaust manifold z With turbocharger z Only replace as assembly 2. Intake manifold 3. from charge air cooler 4. Gasket z Replace z Coating (beading) toward intake manifold 5. 25 N.m (18 ft lb) 6. Gasket z Note installation position 7. Bracket z For heat shield (item -9-) 8. Washer 9. Heat shield z Engage in bracket (item -7-) 10. Turbocharger z Only replace as assembly z Removing: remove right drive shaft at transmission: See FRONT AXLE SHAFT . NOTE: z All hose connections are secured with clips. z Charge air pressure must be leak free. z Replace self-locking nuts. NOTE: The following list refers to items in Fig. 1 .
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Exhaust System, Emission Controls - 1.9L 4-Cyl. - ALH, New Beetle
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Exhaust System, Emission Controls - 1.9L 4-Cyl. - ALH, New Beetle
|
