Volkswagen New Beetle. Manual - part 1253





Fig. 10: Disconnecting Connector From Oxygen Sensor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove warm air collector plate.

z

Remove securing bolts -2- from exhaust pipe on exhaust manifold.

Fig. 11: Removing Securing Bolts From Exhaust Pipe On Exhaust Manifold
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unbolt four upper nuts -1- as well as four lower from exhaust manifold to cylinder head.

z

Remove exhaust manifold upward.

Installing

NOTE:

z

To prevent exhaust gases escaping, the contact surfaces between the
exhaust manifold, exhaust pipe and cylinder head must be bolted together
correctly.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)



Installation is performed in the reverse sequence. Note the following:

z

Tightening torques. See EXHAUST MANIFOLD, FRONT EXHAUST PIPE AND CATALYTIC
CONVERTER WITH ATTACHMENTS
 and ENGINE CODES AVH, AZG, BDC, BEV, BGD

{

Erase fault memory. See ENGINE CONTROL MODULE FAULT MEMORY,
INTERROGATION AND ERASING
 .

SECONDARY AIR SYSTEM

FUNCTION

z

The secondary air system blows air in behind the exhaust valve for a maximum of 100 seconds after the
cold start (+5° C...+33° C coolant temperature). This produces an oxygen rich exhaust gas which initiates
afterburning and reduces the heating-up phase of the catalytic converter.

z

Activation occurs from Motronic Engine Control Module (ECM) -J220- via the Secondary Air Injection
(AIR) pump relay -J229- to Secondary Air Injection (AIR) solenoid valve -N112-, change-over valve and
combination valve. Only vehicles with engine code AEG up to Model Year 1999, 05.99.

z

If the secondary air pump motor is activated it produces an overpressure and opens the combination valve
at 60 to 70 mbar. Only vehicles with engine codes: AEG as of Model Year 1999, 06.99, AVH, AZG,
BDC, BEV and BGD.

z

Additionally after each subsequent engine start (up to max. 96 °C engine temperature) the secondary air
system will switch in for 10 seconds during idling and will be checked by the self-diagnosis. When doing
this the oxygen sensor regulation must be active.

SECONDARY AIR SYSTEM COMPONENTS, REMOVING AND INSTALLING

Engine codes AEG up to Model Year 1999, 05.99

z

Engine codes: AEG as of Model Year 1999, 06.99, AVH, AZG, BEV. See ENGINE CODES: AEG AS
OF MODEL YEAR 1999 (06.99) - AVH, AZG AND BEV
 .

z

Engine codes BDC, BGD. See ENGINE CODES: BDC, BGD .

z

Replace all seals/gaskets and self-locking nuts.

WARNING:

When performing repair work, especially due to the confined conditions
in the engine compartment, pay attention to the following:

z

Route all types of lines (e.g. for fuel, hydraulics, EVAP system,
coolant, refrigerant, brake fluid and vacuum) as well as electrical
wiring so that the original positions are restored.

z

Ensure sufficient clearance to all moving or hot components.

NOTE:

The following list refers to items in Fig. 12 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)



1. Connector

z

2-pin

2. Secondary Air Injection (AIR) solenoid valve -N112-

3. To union on pipe to brake servo

4. Secondary Air Injection (AIR) pump relay -J299-

z

In protective housing for relays. See Secondary Air Injection (AIR) pump relay -J299-

z

In engine compartment (in cable guide next to brake master cylinder)

5. O-ring

z

Replace

6. Pressure hose

z

Check if seated securely

z

Press together at front to release

7. Intake hose

z

From air cleaner upper part

z

For secondary air injection pump

z

Check if seated securely

z

Press together at front to release

8. Secondary Air Injection (AIR) pump motor -V101-

z

Activation via AIR pump relay -J299-

z

Checking function. See SECONDARY AIR INJECTION PUMP MOTOR, CHECKING

9. 10 N.m

10. Retainer

z

For secondary air pump motor

z

Fastened to intake manifold

11. Connector

z

2-pin

12. 25 N.m

13. Intake manifold lower part

14. To union on exhaust manifold

15. 40 N.m

16. Connecting pipe

17. Nuts/bolts, 60 N.m

18. Warm air collector plate

z

With mounting for combination valve

19. Seal

z

Replace

20. Combination valve



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)



z

Checking. See COMBINATION VALVE, CHECKING

z

Removing and installing. See COMBINATION VALVE, REMOVING AND INSTALLING

Fig. 12: Exploded View Of Secondary Air System Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine codes: AEG as of Model Year 1999 (06.99) - AVH, AZG and BEV

1. Combination valve

z

Checking. See COMBINATION VALVE, CHECKING

z

Removing and installing. See COMBINATION VALVE, REMOVING AND INSTALLING

2. Secondary Air Injection (AIR) pump relay -J299-

z

In protective housing for relays. See Secondary Air Injection (AIR) pump relay -J299-

z

In engine compartment (in cable guide next to brake master cylinder)

3. O-ring

z

Replace

4. Pressure hose

z

Check if seated securely

z

Press together at front to release

5. Intake hose

z

From air cleaner upper part

z

For secondary air injection pump

z

Check if seated securely

z

Press together at front to release

6. Secondary Air Injection (AIR) pump motor -V101-

NOTE:

The following list refers to items in Fig. 13 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)
