Volkswagen New Beetle. Manual - part 1252





12. 40 N.m

Fig. 4: Removing And Installing Muffler With Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installation Position Of Double Clamp

Fig. 5: Identifying Installation Position Of Double Clamp
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Work sequence

z

Position double clamp approx. 5 mm away from mark "A" (arrow -2-).

Installation Position Of Mounting

Angled side on base of mounting (arrow) points forward.

NOTE:

z

Mark "A" (arrow -2-) is valid for models with either a manual or an
automatic transmission.

z

Mark "S" (arrow -1-) is not valid for the engine codes in this manual.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 6: Identifying Installation Position Of Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Separating point on exhaust pipe

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

Body saw e.g. V.A.G 1523

Fig. 7: Identifying Separating Point On Exhaust Pipe
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Work sequence

z

Separate exhaust pipe at right angles at separating point (arrow -2-).

z

When installing, position repair double clamp -4- at side markings (arrows -1- and -3-). Tighten torque:
40 N.m

Aligning Center Muffler Stress Free



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)



The mounting pins on the exhaust pipe must run parallel with the tunnel bridge (dimension -x- on left and right
is the same).

Fig. 8: Aligning Center Muffler Stress Free
Courtesy of VOLKSWAGEN OF AMERICA, INC.

MUFFLER, REMOVING AND INSTALLING

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

V.A.G 1331 Torque wrench (5...50 N.m)

Removing

z

Remove engine cover.

z

Unscrew wiper arms (M8 hex nuts = 20 N.m).

See WIPER ARMS .

z

Remove plenum chamber cover (outer) and plenum chamber sealing part.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 9: Identifying V.A.G 1331 Torque Wrench
Courtesy of VOLKSWAGEN OF AMERICA, INC.

See PLENUM CHAMBER SEALING ASSEMBLY, REMOVING AND INSTALLING .

z

Remove intake manifold upper part: See INTAKE MANIFOLD UPPER PART, REMOVING AND
INSTALLING
 .

z

Pull pressure and vacuum hoses off combination valve.

z

Remove connecting pipe between combination valve and exhaust manifold.

z

Remove insulation tray.

See NOISE INSULATION, ASSEMBLY OVERVIEW .

z

Remove right hand inner constant velocity joint protective cover from engine if installed.

z

Remove engine/exhaust manifold support.

z

Disconnect connector for oxygen sensor -1- and move wiring clear.

NOTE:

Seal the intake ports in the intake manifold lower part with clean cloths.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)
