Fig. 8: Connecting In Turbocharger Tester VAG 1397 A Using T-Piece
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Select measuring range -I-.

Measuring charge pressure at wide open throttle:

NOTE:

z

Operating turbocharger tester. See operating instructions.

z

The hoses must be connected so that there is no possibility of leaks.

z

If charge pressure is measured while driving, it is necessary (for safety
reasons) for a second person to operate the turbocharger tester.

z

Ensure that the pressure hose is not trapped between the hood and the
body.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



z

Accelerate with wide open throttle from 2000 RPM in 3rd gear or in 2nd driving range.

z

At 3000 RPM press memory button "M" on turbocharger tester.

Specification: (absolute pressure) 1.300-1.400 bar

If the charge pressure is exceeded:

z

Disconnect connector -2- from Wastegate Bypass Regulator Valve -N75- -1-.

Fig. 9: Disconnecting Connector From Wastegate Bypass Regulator Valve -N75
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check hose from connecting pipe (between turbocharger and charge air cooler) via valve to vacuum
diaphragm for clogging.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



z

Check that pressure unit for charge pressure regulator valve is securely mounted on turbocharger.

z

Check shaft mount for regulator valve in turbocharger for ease of movement. When corroded together,
replace turbocharger.

If the charge pressure is not attained:

z

Check Wastegate Bypass Regulator Valve -N75-.

Charge air pressure regulation, checking (AWP, AWV)

Special tools and equipment

z

VAG 1551 scan tool

NOTE:

The vehicle system tester VAG 1552 can be used instead of the VAG 1551
scan tool, however a print-out is not possible.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 10: Identifying VAG 1551 Scan Tool
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAG 1551 /3B Cable

Fig. 11: Identifying VAG 1551 /3B Cable
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test conditions

z

Check and erase DTC memory, if necessary:

See Diagnostic Trouble Code (DTC) Memory, Checking And Erasing .

z

No leaks on intake and exhaust systems
