Volkswagen New Beetle. Manual - part 1190





Fig. 15: Securing Engine To Support Clamp VW 313 Using Engine And Transmission Bracket VW
540

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installation notes

Installation is carried out in the reverse sequence. Also note the following:

z

Check whether dowel sleeves for centering engine/transmission are in cylinder block, install if necessary.

z

Install intermediate plate onto sealing flange and slide onto dowel sleeves -arrows-.

CAUTION: When doing any repair work, especially in the engine compartment, due to

the cramped conditions, pay attention to the following:

z

Route all sorts of lines (e.g. for fuel, hydraulics, EVAP system,
coolant, refrigerant, brake fluid and vacuum lines and hoses, etc.)
and electrical wiring so that the original positions are restored.

z

Ensure sufficient clearance to all moving or hot components.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 16: Installing Intermediate Plate Onto Sealing Flange And Sliding Onto Dowel Sleeves
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with manual transmission

z

Check centering of clutch drive plate, if necessary.

z

Check clutch release bearing for wear, replace if necessary.

z

Lightly grease clutch release bearing, release bearing guide sleeve and splines on input shaft with G 000
100.

Vehicles with manual transmission 02J

z

Install hydraulic clutch slave cylinder:

See CLUTCH SLAVE CYLINDER

z

Install selector mechanism.

See SELECTOR MECHANISM ON TRANSMISSION SIDE, UP TO 05.99, DISASSEMBLING
AND ASSEMBLING
 or SELECTOR MECHANISM ON TRANSMISSION SIDE, AS OF 06.99,
DISASSEMBLING AND ASSEMBLING


z

If necessary, adjust shifter cables:

See SELECTOR MECHANISM

Vehicles with manual transmission 02M

z

Install hydraulic clutch slave cylinder:

See CLUTCH RELEASE BEARING/SLAVE CYLINDER



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

Install selector mechanism.

See SELECTOR LEVER LOCK SOLENOID

z

If necessary, adjust shifter cables:

See SELECTOR MECHANISM

Vehicles with automatic transmission

z

Only use nuts approved in parts program to secure torque converter to drive plate.

z

Install selector cable on transmission, adjust if necessary:

See SELECTOR LEVER CABLE

z

Adapt control module for automatic transmission:

See BASIC SETTING, INITIATING

Continued for all vehicles

z

When installing assembly, ensure sufficient clearance to drive shafts.

Vehicles with air conditioner

z

Install generator.

See GENERATOR

z

Install compact bracket including tightening element for ribbed V-belt. See COMPACT BRACKET ,
item 22.

PART I

z

Install A/C compressor.

Continued for all vehicles

z

Align engine and transmission mounts. See ENGINE AND TRANSMISSION MOUNTS,
ALIGNING
 .

z

Install drive shafts:

See FRONT AXLE SHAFT

z

Install right hand inner constant velocity joint protective cover from engine.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

Install front exhaust pipe. See EXHAUST SYSTEM COMPONENTS, REMOVING AND
INSTALLING
 .

z

Install intake hose (between charge air cooler and Throttle Valve Control Module) onto Throttle Valve
Control Module -J338- and secure.

z

Install power steering pump:

See POWER STEERING PUMP IN LOWER SECTION, ASSEMBLY OVERVIEW or POWER
STEERING PUMP IN UPPER SECTION, ASSEMBLY OVERVIEW


z

Check electrical connections and routing:

See appropriate WIRING DIAGRAM article.

z

Install ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING .

z

Install center, left and right insulation trays:

See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING

Fig. 17: Installing Center, Left And Right Insulation Trays
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install secondary air pump.

z

Install connecting hoses between secondary air pump to combination valve and secondary air pump to air
cleaner.

z

Fill with coolant. See COOLING SYSTEM, DRAINING AND FILLING .

z

Perform work sequence "Procedure after correcting voltage supply open circuit".

See PROCEDURE AFTER CORRECTING VOLTAGE SUPPLY OPEN CIRCUIT .

z

Test drive vehicle.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
