Volkswagen New Beetle. Manual - part 1188





Fig. 4: Pulling Off Supply Line/Hose And Return Line/Hose
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Seal pipes so that fuel system is not contaminated by dirt etc.

z

Pull hose off solenoid valve.

z

Loosen and remove intake hose (between charge air cooler and Throttle Valve Control Module -J338-) at
Throttle Valve Control Module -J338-.

z

Disconnect harness connector for Intake Air Temperature (IAT) sensor -G42-, -1- and -4- for Throttle
Valve Control Module -J338- below Throttle Valve Control Module -J338-.

Fig. 5: Disconnecting Harness Connector For Intake Air Temperature Sensor G42
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull connector off Camshaft Position (CMP) sensor -G40- -arrow-.

NOTE:

Press buttons on hose couplings to do this.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 6: Pulling Connector Off Camshaft Position Sensor G40
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unbolt vacuum canister from cylinder head cover and pull from bracket.

z

Disconnect fuel injectors harness connector and unclip bracket rail from fuel distributor.

z

Unscrew Ground wire between ignition coil -1- and -2-.

z

Disconnect connectors from ignition coils.

z

Disconnect connector for speedometer Vehicle Speed Sensor -G22- at rear of transmission.

z

Remove center, left and right insulation tray:

See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING .

z

Remove air duct to charge air cooler at lower right of long member.

Fig. 7: Removing Air Duct To Charge Air Cooler At Lower Right Of Long Member
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Vehicles with manual transmission 02J

z

Disconnect selector mechanism from transmission.

See SELECTOR MECHANISM ON TRANSMISSION SIDE, UP TO 05.99, DISASSEMBLING
AND ASSEMBLING
 or SELECTOR MECHANISM ON TRANSMISSION SIDE, AS OF 06.99,
DISASSEMBLING AND ASSEMBLING
 .

z

Remove hydraulic clutch slave cylinder.

See CLUTCH SLAVE CYLINDER .

Vehicles with manual transmission 02M

z

Disconnect selector mechanism from transmission.

See SELECTOR LEVER LOCK SOLENOID .

z

Remove hydraulic clutch slave cylinder.

See CLUTCH RELEASE BEARING/SLAVE CYLINDER .

Vehicles with automatic transmission

z

Remove selector lever cable from transmission:

See SELECTOR LEVER CABLE .

Continued for all vehicles

z

Drain coolant. See COOLING SYSTEM, DRAINING AND FILLING .

z

Pull radiator coolant hoses off engine.

z

Remove coolant hoses at heater core.

z

Remove coolant hose to coolant pipe at Throttle Valve Control Module -J338-.

NOTE:

Clutch pedal must not be depressed.

WARNING:

Observe proper disposal regulations!

NOTE:

The VAS 5024 assembly tool or VAG 1921 pliers are recommended for
removing and installing the spring-type clamps.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

Remove additional fan at right side of vehicle if present.

z

Disconnect both harness connectors for cooling fan at notch at left bottom.

z

Remove inter-connecting, coolant, vacuum and intake hoses on engine.

z

Remove connecting hoses -arrows- between secondary air pump/combi-valve and secondary air pump/air
cleaner.

Fig. 8: Removing Connecting Hoses Between Secondary Air Pump/Combi-Valve And Secondary
Air Pump/Air Cleaner

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull connector -1- off secondary air pump.

z

Remove secondary air pump motor and bracket.

z

Disconnect all electric wires from transmission, alternator and starter and move clear.

z

Remove securing clamps for power steering pressure pipe.

z

Remove ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING .

z

Remove power assisted steering vane pump with bracket and lay to side; hoses remain connected.

See POWER STEERING PUMP, RESERVOIR, HYDRAULIC LINES .

Vehicles with air conditioner

z

Remove air conditioner compressor.

z

Observe additional notes and assembly work. See INSTALLATION NOTES .

z

Remove generator.

NOTE:

Press buttons on hose couplings to do this.

WARNING:

The air conditioner refrigerant circuit must not be opened.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
