Volkswagen New Beetle. Manual - part 1184





Fig. 149: Loosening Securing Bolts On Oil Pump Balancer Shaft Gear Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing and adjusting oil pump with balancer shaft gear assembly

Requirements

z

Chain tensioner pre-tensioned. See PRE-TENSIONING CHAIN TENSIONER

z

Install oil pump with balancer shaft gear assembly. Tighten securing bolts (starting on inside and working
outward) to 15 N.m + 1/4 turn (90°) further.

Fig. 150: Locating Oil Pump With Balancer Shaft Gear Assembly Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Set crankshaft to TDC No. 1 cylinder.

NOTE:

Observe different lengths of bolts. See Fig. 137 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 151: Locating Marks For Setting Crankshaft To TDC No. 1 Cylinder
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Align mark on balancer shaft chain sprocket (arrow) with fixture hole. Lock chain sprocket in this
position with pin T10060. Fit chain onto balancer shaft chain sprocket.

Fig. 152: Aligning Mark On Balancer Shaft Chain Sprocket With Fixture Hole
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Position milled side of oil pump shaft so that it is facing forward.

z

Install oil pump chain sprocket and tighten bolt hand tight.

z

Remove locking pin T10060 and Allen key -1-. Secure oil pump chain sprocket.

NOTE:

The oil pump chain sprocket only fits in one position. Only the oil pump
may be turned when installing.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 153: Removing Locking Pin And Allen Key
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Tightening torque: 20 N.m. Counter support on central bolt of vibration damper.

The rest of the assembly is basically in reverse order to the disassembly sequence.

Oil sump, removing and installing

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

3185 Jointed wrench

z

T10058 Socket

z

V.A.G1331 Torque wrench (5...50 N.m)

z

Hand drill with plastic brush attachment

z

Silicone sealing compound D 176 404 A2



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 154: Identifying Special Tools
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove center and right insulation trays:

See NOISE INSULATION, ASSEMBLY OVERVIEW .

Engines with oil sump protection

1. Rubber grommet

z

located in cylinder block

2. Bolt, 37 N.m

3. Spreader rivet

4. Oil sump protection

{

To remove spreader rivet -3- push upward. See Fig. 138

{

Have a second technician push oil sump protection -4- against oil sump.

Fig. 155: Removing Oil Sump Protection
Courtesy of VOLKSWAGEN OF AMERICA, INC.

{

Loosen bolts -2-.

{

Carefully remove oil sump protection -4-

Continuation for all models

NOTE:

For engine code BEV, the oil sump is composed of two parts (upper and lower).
The oil sump can be dismounted complete from its union to the engine block. If
it is necessary, the upper part may be separated from the lower part. See Part I
(Engine code BEV) .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
