Volkswagen New Beetle. Manual - part 1182





Dowel sleeves. See Fig. 132 , item 8 above oil pump.

z

Installed position of oil pump shaft/chain sprocket: Can only be installed in one position.

Installing sump and baffle plate. See OIL SUMP, REMOVING AND INSTALLING

Tightening torques. See Part I (Engine codes AEG, AVH, AZG)

Oil pump with balancer shaft gear assembly, disassembling and assembling (Engine codes BDC, BGD)

1. Chain guard

2. Chain

z

Mark direction of rotation before removing (installation position)

3. Dowel sleeves

4. Oil pump with balancer shaft gear assembly

z

Before installing, check that both dowel sleeves for centralizing are installed

5. 3 N.m

z

Insert with locking compound D 000 600 A2

6. Cover

z

Prevents engine oil foaming

7. Oil return union

z

With seal/gasket

8. 9 N.m

9. Suction line

z

Clean strainer if soiled

10. 8 N.m

11. O-ring

z

Replace

12. 15 N.m + 1/4 turn (90°) further

z

Observe different lengths of bolts. See Fig. 137

13. O-ring

z

Replace

14. Sealing plug, 15 N.m + 1/4 turn (90°) further

15. Dowel sleeves

16. Outer rotor

z

Check running surfaces for scoring

z

Marking(s) must be visible

NOTE:

The following list refers to items in Fig. 141 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



17. Inner rotor

z

Check running surfaces for scoring

18. Oil pump cover

19. 8 N.m

20. Chain sprocket

21. 20 N.m

22. Chain tensioner with tensioning plate

z

Pre-tension when installing. See PRE-TENSIONING CHAIN TENSIONER

23. 15 N.m

Fig. 141: Exploded View Of Oil Pump With Balancer Shaft Gear Assembly (Engine Codes BDC, BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pre-tensioning chain tensioner

z

Tension piston by hand (arrow).

Fig. 142: Tensioning Piston (Engine Codes BDC, BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press chain rail in direction of arrow and lock with a 3 mm Allen key -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 143: Pressing Chain Rail (Engine Codes BDC, BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Oil pump with balancer shaft gear assembly, removing and installing

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

T10060 Locking pin

Removing

z

Remove oil sump. See OIL SUMP, REMOVING AND INSTALLING



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 144: Identifying Special Tool T10060
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull chain guard off. Release locking lugs by inserting a small screwdriver through openings (arrows) if
necessary.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
