z

Fit new valve stem seal into installation tool 3129.

z

Oil valve stem seal sealing lip and press carefully onto valve guide.

ENGINE - LUBRICATION

LUBRICATION SYSTEM

Lubrication system components, removing and installing

Disassembling and assembling oil filter bracket. See Part II (Oil filter housing, disassembling and
assembling)
 .

Engine codes BDC, BGD

Disassembling and assembling oil pump with balancer shaft gear assembly. See Oil pump with balancer shaft
gear assembly, disassembling and assembling (Engine codes BDC, BGD)
 .

Removing and installing oil pump with balancer shaft gear assembly. See OIL PUMP WITH BALANCER
SHAFT GEAR ASSEMBLY, REMOVING AND INSTALLING
 .

Continuation for all models

Checking oil pressure and oil pressure switch. See OIL PRESSURE AND OIL PRESSURE SWITCH,
CHECKING
 .

Engine oil specifications

Use engine oils which conform with VW standard 500 00, 501 01 or 502 00. Only in exceptional cases: Multi-
grade and single grade oils conforming with API-SF and SG or ACE A A2/A3.

NOTE:

z

Metal shavings or large amounts of small metal particles found in the
engine oil during repairs may be caused by a partial seizure of the
crankshaft or connecting rod bearings. Perform the following work
sequences in this situation to prevent consequential damage once repairs
are complete:

{

Thoroughly clean oil passages

{

Replace oil spray jets

{

Replace oil cooler

{

Replace oil filter

z

The oil level must not be above the max. mark or there is a danger of
damage to catalytic converter. For markings, see Fig. 136 .

NOTE:

z

In the factory the engine is filled with engine oil conforming with VW
standard 503 00. This engine oil is designed for long service intervals



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Oil system capacity

See ENGINE OIL LEVEL, CHECKING .

Part I (Engine codes AEG, AVH, AZG)

Part II, Disassembling and assembling oil filter housing. See Part II (Oil filter housing, disassembling and
assembling)
 .

z

For engine codes BDC, BGD, see Part I (Engine codes BDC, BGD) .

z

For engine code BEV, see Part I (Engine code BEV) .

1. 15 N.m

2. Sealing flange

z

Must be located on dowel sleeves

z

Insert with silicone sealant D 176 404 A2. See FRONT SEALING FLANGE, REMOVING
AND INSTALLING


z

Removing and installing. See FRONT SEALING FLANGE, REMOVING AND INSTALLING

z

Replacing crankshaft oil seal, poly V-belt pulley end. See CRANKSHAFT OIL SEAL -
PULLEY END, REPLACING


3. Pressure relief valve, 27 N.m

4. Oil spray jet

z

For piston cooling

5. Dipstick

z

Oil level must not exceed max. mark!

z

Markings. See Fig. 135

6. Dipstick guide

z

Fastened to intake manifold

z

Pull off to extract oil

7. Guide tube

8. Dowel sleeves

9. O-ring

z

Replace

10. 15 N.m

(ESI).

z

Engine oils conforming to VW standard 500 00, 501 01 or 502 00 may also
be used.

NOTE:

The following list refers to items in Fig. 132 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



11. Suction line

z

Observe part number

z

Clean strainer if soiled

12. Baffle plate

13. 15 N.m

14. Oil sump protection

z

Not for all engines. See Parts catalog.

z

Assembly overview. See Fig. 138

15. Oil drain plug, 30 N.m

z

Replace if leaking. See Parts catalog for correct application. In some cases seal and drain plug are
combined; do not interchange with separate seal and drain plug.

16. Oil sump

z

Clean sealing surface before installing

z

Insert with silicone sealant D 176 404 A2. See OIL SUMP, REMOVING AND INSTALLING .

z

Removing and installing. See OIL SUMP, REMOVING AND INSTALLING .

17. Oil pump

z

With pressure relief valve of 12 bar

z

Before installing, check that both dowel sleeves for centralizing oil pump/cylinder block are
installed

z

Replace if running surfaces and gears are scored

z

Removing and installing. See Oil pump, removing and installing (Engine codes AEG, AVH,
AZG, BEV)
 .

18. Chain sprocket

z

Observe installing position

19. 20 N.m

z

Use counter support T10051 to loosen and tighten

20. Chain

21. Chain tensioner with tensioning rail, 15 N.m

z

When installing, pretension spring and fit



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 132: Exploded View Of Lubrication System Components (Engine Codes AEG, AVH, AZG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Part I (Engine codes BDC, BGD)

z

For engine codes AEG, AVH, AZG. See Part I (Engine codes AEG, AVH, AZG) .

z

For engine code BEV. See Part I (Engine code BEV) .

1. 15 N.m

2. Sealing flange

z

Must be seated on dowel sleeves

z

Insert with silicone sealant D 176 404 A2. See FRONT SEALING FLANGE, REMOVING
AND INSTALLING
 .

z

Removing and installing. See FRONT SEALING FLANGE, REMOVING AND
INSTALLING
 .

z

Replacing crankshaft oil seal, ribbed belt pulley end. See CRANKSHAFT OIL SEAL - PULLEY
END, REPLACING
 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
