Adjusting valve timing.

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

10-222 A Support device (Modifying guide 10-222 A/21. See MODIFYING GUIDE 10-222 A/21
FROM SUPPORT DEVICE 10-222 A )

z

10-222 A/8 Adapter

z

V.A.G 1331 Torque wrench (5...50 N.m)

z

V.A.G 1332 Torque wrench (40...200 N.m)

z

T 10020 Two-hole pin wrench

Fig. 69: Identifying Special Tools
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Modifying guide 10-222 A/21 from support device 10-222 A



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Support device 10-222A is required to support engine/transmission assembly.

A new hole is required on guide 10-222 A/21 to secure adapter 10-222 A/8.

Fig. 70: Identifying 10-222 A/21 & 10-222 A/8
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Dimensions given are in mm.

z

Drill a 12.5 mm diameter (arrow) in guide 10-222 A/21.

Removing

z

Remove engine cover.

z

Removing right side insulation tray:

See NOISE INSULATION, ASSEMBLY OVERVIEW

z

Remove ribbed belt. See RIBBED BELT, REMOVING AND INSTALLING .

z

Remove tensioning element for ribbed belt.

z

Remove coolant expansion tank (coolant hoses remain connected).

z

Remove toothed belt guard, upper part.

z

Set camshaft pulley to TDC No. 1 cylinder by turning crankshaft.

Mark on camshaft sprocket must align with arrow on toothed belt guard



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 71: Aligning Mark On Camshaft Sprocket With Arrow On Toothed Belt Guard
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Mount support 10-222A with legs 10-222A/8 as shown.

Fig. 72: Mounting Support With Legs On Engine
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove engine mounting -1- as follows:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 73: Removing Engine Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.
