Volkswagen New Beetle. Manual - part 1167





z

Only engine codes BDC, BGD to Positive Crankcase Ventilation (PCV) heating element -N79-

5. Shaped hose

z

Engine codes AVH, AZG through Model Year 2001

6. Shaped hose

z

Engine codes AVH, AZG from Model Year 2002

z

Engine codes BDC, BEV and BGD

z

Do not remove union between intake manifold hose and shaped hose.

7. To intake manifold upper part

z

Only Model Year from 2002

8. Seal

z

Replace

9. Sealing plug, 15 N.m

z

Replace

10. Cylinder head bolt

z

Replace

z

Remove and install Polydrive cylinder head bolt with 3452

z

Sequence when loosening and tightening. See CYLINDER HEAD, REMOVING AND
INSTALLING


11. Connecting unions

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM

12. 10 N.m

13. Seal

z

Replace

14. 20 N.m

15. Lifting eye

16. Cylinder head gasket

z

Replace

z

After replacement replace entire coolant amount

17. 15 N.m

18. 20 N.m

19. Rear toothed belt guard

20. Toothed belt

z

Mark direction of rotation before removing

z

Check for wear

z

Do not kink

z

Removing, installing and tensioning. See TOOTHED BELTS, REMOVING, INSTALLING
AND TENSIONING


21. Cylinder head



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

Check for distortion. See Fig. 68

z

Reworking sealing surface. See Fig. 102

z

Removing and installing. See CYLINDER HEAD, REMOVING AND INSTALLING

z

After replacement replace entire coolant amount

22. Oil deflector

23. Cylinder head cover gasket

z

Replace if damaged

z

Coat cylinder head/bearing cap transition points with D 454 300 A2 before installing

24. Cylinder head cover

z

With cable guide



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 67: Exploded View Of Cylinder Head Cylinder Head (Aluminum Cylinder Head Cover)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking Cylinder Head For Distortion



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 68: Checking Cylinder Head For Distortion
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Max. permissible distortion: 0.1 mm

Toothed belts, removing, installing and tensioning



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
