Volkswagen New Beetle. Manual - part 1145





Knock Sensor (KS) 2 -G66-

Secondary Air Injection (AIR) pump motor -V101-

Oil pressure switch -F1-

if installed, A/C cut-out thermal switch -F163-

Mass Air Flow (MAF) sensor -G70-

Throttle valve control module -J338-

z

Unbolt secondary air injection pump and bracket and remove.

z

Disconnect all electric wires from transmission, Generator and starter and move clear.

z

Disconnect all other electrical connections as necessary from engine and lay to one side.

z

Unbolt pendulum support (arrows).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 8: Removing Pendulum Support Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove protective cover for right side inner constant velocity joint from engine.

z

Remove right side axle shaft and disconnect left-hand drive shaft at transmission:

See FRONT AXLE SHAFT .

z

Remove front exhaust pipe. See EXHAUST MANIFOLD, FRONT EXHAUST PIPE AND
CATALYTIC CONVERTER WITH ATTACHMENTS
 .

z

Disconnect connection for oxygen sensor before catalytic converter (under vehicle floor).

z

Remove oil sump protection. See Fig. 138 .

z

Insert engine bracket T 10012 in engine/transmission jack V.A.G 1383 A.

z

Remove bracket on cylinder block for lower coolant hose. Threaded hole is required to secure engine
bracket T10012.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

Secure engine bracket T10012 to front of cylinder block with securing bolt M10 x 25/ 8.8 to 40 N.m.

Fig. 9: Securing Engine Bracket To Front Of Cylinder Block
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tighten securing nut on exhaust side hand tight.

z

Lift engine and transmission lightly using engine/transmission jack V.A.G 1383 A.

z

Unbolt engine side of assembly mounting from engine carrier at top (arrows).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 10: Removing Engine Side Of Assembly Mounting Bolts From Engine Carrier At Top
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unbolt transmission side of assembly mounting from top of transmission carrier (arrows).

NOTE:

Use ladder VAS 5085 to remove securing bolts.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
