Volkswagen New Beetle. Manual - part 1140





Part II

1. Sealing plug

z

25 N.m (18 ft lb)

2. Gasket

z

Always replace

3. Oil cooler

z

Make sure clearance between adjacent components

z

See note. See LUBRICATION SYSTEM COMPONENTS, REMOVING AND INSTALLING

4. Gasket

z

Always replace

z

Install into oil cooler groove

5. Seal

z

If seal leaks, nip open and replace.

6. Plug

z

10 N.m (7 ft lb)

7. Sealing plug

z

Do NOT open

8. Spring

z

For pressure relief valve, approx. 5 bar

9. Piston

z

For pressure relief valve, approx. 5 bar

10. 0.9 bar oil pressure switch -F1-

z

25 N.m (18 ft lb)

z

Gray

z

Checking: See OIL PRESSURE AND OIL PRESSURE SWITCH, CHECKING

11. Gasket

z

Always replace

12. 15 N.m (11 ft lb) plus additional1/4 turn (90°)

z

Always replace

z

Place bolts first top left and right, then tighten all four bolts over cross

13. Oil filter bracket

14. Seal

z

Always replace

15. Oil supply pipe

z

To the turbocharger

NOTE:

The following list refers to items in Fig. 103 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



16. Banjo bolt

z

20 N.m (15 ft lb)

17. Sealing cap

z

25 N.m (18 ft lb)

z

Loosen and tighten using 3417 oil filter wrench

18. O-ring

z

Always replace

19. Oil filter element

Fig. 103: Exploded View Of Oil Filter Bracket Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Dipstick, markings

1. MAX. mark

2. MIN. mark

a. Area above cross-hatched zone up to the MAX. mark:

Do not top-up with engine oil!

b. Oil level within cross-hatched zone:

Can be topped-up with engine oil, as necessary

c. Area from MIN. mark up to cross-hatched zone:

Fill with 0.5 ltr. (.47 quarts) of engine oil maximum!

NOTE:

The following lists refers to items in Fig. 104 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 104: Identifying Oil Level Mark On Dipstick
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Oil pan, removing and installing

Special tools and equipment

z

Hand drill with plastic brush

z

D 176 404 A2 Silicone sealant

z

Scraper

Oil pan, removing

z

Remove center, left and right insulation trays:

See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING

z

Drain engine oil.

z

Unscrew oil pan.

z

Loosen oil pan with light blows from a rubber hammer, if necessary.

z

Remove sealant residue on cylinder block with a flat scraper.

z

Remove sealant residue on the oil pan with a rotating brush, e.g. a hand drill with a plastic brush (wear
protective glasses).

z

Clean sealing surfaces, must be free of oil and grease.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 105: Removing Sealant Residue On Oil Pan
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Cut-off tube nozzle at forward mark (approx. 3 mm diameter).

z

Apply silicone sealing compound as shown to a clean oil pan sealing surface.

z

Bead must be: 2 to 3 mm thick.

z

Bead must run on the inside of bolt holes (arrows).

NOTE:

z

Note the "use by date" on the sealant container.

z

Oil pan must be installed within 5 minutes after applying the silicone
sealing compound.

NOTE:

The sealing bead must not be thicker, or excess compound will enter



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
