Volkswagen New Beetle. Manual - part 1138





Camshaft, removing and installing

Special tools and equipment

z

3359 Rig pin

z

3418 Adjustment guide

z

V159 Nut wrench

z

VAG 1331 Torque wrench: 5 to 50 N.m (3.7 to 37 ft lb)

Fig. 96: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove connecting pipe between charge air cooler and intake hose. See CHARGE AIR COOLER
COMPONENTS, REMOVING AND INSTALLING


z

Remove toothed belt guard, upper section.

z

Remove valve cover.

z

Remove brake booster vacuum pump.

Vehicles with manual transmission:

z

Turn crankshaft to cyl. 1 TDC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 97: Identifying Mark (Vehicles With Manual Transmission)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with automatic transmission:

z

Turn crankshaft to cyl. 1 TDC.

Fig. 98: Identifying Mark (Vehicles With Automatic Transmission)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lock camshaft with setting bar.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 99: Installing Setting Bar On Camshaft
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Release tensioning roller and take toothed belt off camshaft sprocket.

z

Loosen camshaft sprocket mounting bolt 1/2 turn.

z

Release camshaft sprocket from camshaft taper by tapping with a hammer (using a drift through rear
toothed belt guard opening).

z

Take off camshaft sprocket.

z

First remove bearing caps 5, 1 and 3. Then loosen bearing caps 2 and 4 alternately and diagonally.

Installing

NOTE:

z

When installing the camshaft, No. 1 cylinder cams must point upward.

z

When installing the bearing cap, note offset before installing camshaft,
install bearing caps and determine installed position.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Oil camshaft contact surfaces.

z

Install camshaft.

z

Tighten bearing caps: 2 and 4 alternately and diagonally

z

20 N.m (15 ft lb)

z

Install bearing caps: 5, 1 and 3.

z

20 N.m (15 ft lb)

z

Position bearing cap 5 by gently tapping on end of camshaft.

z

Install camshaft sprocket.

z

Install toothed belt and tension. See TOOTHED BELTS, REMOVING, INSTALLING,
TENSIONING
 .

Assembly is basically a reverse of the disassembly sequence.

Hydraulic lifters, checking

Special tools and equipment

z

Feeler gauge

z

Wood or plastic wedge

Test sequence

z

Start engine and run until engine oil temperature is 80° C minimum

z

Increase engine speed to 2500 RPM for approx. 2 minutes.

If lifters are still noisy, locate faulty lifter(s) as follows:

z

Remove valve cover.

z

Rotate crankshaft clockwise, until cam of lifter to be checked is pointing upward.

z

Measure play between cam and lifter.

If play is in excess of 0.1 mm

Fig. 100: Identifying Bearing Caps Position
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

Do NOT start the engine for approx. 30 minutes after new lifters have been
installed. Hydraulic compensation elements must settle (otherwise the
valves will strike pistons).

NOTE:

z

Replace faulty lifter assembly (cannot be adjusted or repaired).

z

Irregular valve noises are normal when starting the engine.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
