Volkswagen New Beetle. Manual - part 1134

1. Bearing cap

z

Installation position. See Camshaft bearing caps, installed position

z

Installation sequence. See CAMSHAFT, REMOVING AND INSTALLING

2. 20 N.m (15 ft lb)

3. Camshaft

z

Axial clearance, checking. See Camshaft axial clearance, checking

z

Removing and installing: See CAMSHAFT, REMOVING AND INSTALLING

z

Checking radial clearance with plastigage Wear limit: 0.11 mm

z

Run-out: max. 0.01 mm

z

Identification and valve timing. See Identification

4. Hydraulic lifter

z

Do not interchange

z

Checking. See HYDRAULIC LIFTERS, CHECKING

z

Store with cam contact surface facing downward

z

Before installing, check camshaft axial clearance. See Camshaft axial clearance, checking

z

Oil contact surfaces

5. Keepers

6. Upper valve spring plate

7. Valve spring

z

Removing and installing: With cylinder head removed Use 2037 With cylinder head installed. See
VALVE STEM SEALS, REPLACING

8. Valve stem seal

z

Replacing. See VALVE STEM SEALS, REPLACING

9. Valve guide

z

Checking. See VALVE GUIDES, CHECKING

z

Replacing. See VALVE GUIDES, REPLACING

z

Service version with collar

10. Oil seal

z

To remove and install, remove bearing cap

z

Toothed belt, removing and installing. See TOOTHED BELTS, REMOVING, INSTALLING,
TENSIONING

11. Cylinder head

NOTE:

Cylinder heads with cracks between the valve seats may be used without
reducing engine life, provided the cracks are small and not more than 0.5 mm
wide.

NOTE:

The following list refers to items in Fig. 80 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

See note. See VALVE TRAIN, SERVICING

z

Valve seats, reworking. See VALVE SEATS, REWORKING

12. Valves

z

Valve dimensions. See Valve dimensions

Fig. 80: Identifying Valve Train
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Camshaft axial clearance, checking



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 81: Checking Camshaft Axial Clearance
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Special tools and equipment

z

VW 387 Universal dial gauge bracket

z

Dial gauge

NOTE:

Check with hydraulic lifters removed and with first and last bearing caps



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Wear limit: max. 0.15 mm

Camshaft bearing caps, installed position

Fig. 82: Identifying Camshaft Bearing Caps Position
Courtesy of VOLKSWAGEN OF AMERICA, INC.

fitted.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
