Volkswagen New Beetle. Manual - part 1133





Fig. 76: Identifying Screw Guide Pins
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install new cylinder head gasket.

z

Lettering (Part No.) must be readable.

z

Install cylinder head, screw in 8 remaining head bolts and tighten by hand.

z

Remove guide pins with removal tool from 3070 by turning removal tool counter-clockwise until pins are
free

z

Install remaining cylinder head bolts and tighten hand-tight.

z

Tighten cylinder head in following four stage sequence:

z

Tighten initially using torque wrench:

Stage I = 40 N.m (30 ft lb)

Stage II = 60 N.m (44 ft lb)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Turn further with a normal wrench:

Stage III 1/4 turn (90°)

Stage IV 1/4 turn (90°)

Assembly is basically a reverse of the disassembly sequence.

z

Installing toothed belt and timing adjustment. See TOOTHED BELTS, REMOVING, INSTALLING,
TENSIONING


z

Coolant, filling. See COOLING SYSTEM, DRAINING AND FILLING

Fig. 77: Tightening Cylinder Head Bolts In Sequence
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Compression pressure, checking



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Special tools and equipment

z

3220 Hinged socket

z

VAG 1331 Torque wrench: 5 to 50 N.m (3.7 to 37 ft lb)

z

VAG 1381/12 Adaptor

z

VAG 1763 Compression tester

Fig. 78: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirement

z

Engine oil temperature must be 30°C minimum.

Test sequence



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Disconnect fuel cut-off valve on Diesel injection pump.

z

Disconnect Quantity adjuster harness connector on Diesel injection pump.

z

Remove all glow plugs using 3220 flexible wrench.

z

Screw in VAG 1381/12 adaptor in place of glow plugs.

Fig. 79: Checking Compression With Compression Tester
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check compression using VAG 1763 compression tester.

z

Operate starter until tester display shows no further increase.

Compression pressure:

z

New: 25 to 31 bar

z

Wear limit: 19 bar

Permissible difference between all cylinders:

z

5 bar

z

Install glow plugs using 3220 flexible wrench

z

Tightening torque: 15 N.m (11 ft lb)

z

Check Diagnostic Trouble Code (DTC) memory:

See DTC MEMORY, CHECKING

VALVE TRAIN, SERVICING

NOTE:

Trouble codes will be stored because the Diesel injection pump harness
connector has been disconnected. Check and erase DTC memory.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
