Volkswagen New Beetle. Manual - part 1128





Cylinder bores, checking

Special tools and equipment

z

Internal dial gauge 50 to 100 mm

z

Take measurements at 3 positions in both lateral -A- and longitudinal -B- directions, as illustrated.

z

Deviation from nominal dimension: 0.10 mm maximum

Fig. 61: Checking Cylinder Bores
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Piston installation position and piston/cylinder allocation

Piston in cylinders 1 and 2:

Larger intake valve chamber points toward flywheel (arrows)

Piston in cylinders 3 and 4:

Larger intake valve chamber points toward belt pulley side (arrows).

Piston ring
Dimensions in mm

New

Wear limit

1st compression ring

0.06 to 0.09

0.25

2nd compression ring

0.05 to 0.08

0.25

Oil scraper ring

0.03 to 0.06

0.15

NOTE:

Do NOT measure the cylinder bores when the block is mounted on a repair
stand using the VW 540 adaptor bracket. Bending stresses resulting from
the mass overhang will make incorrect measurements likely.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 62: Identifying Piston Installation Position
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Piston for cylinder 1 and 2: marked 1/2

z

Piston for cylinder 3 and 4: marked 3/4

Piston projection at TDC, checking

Special tools and equipment

z

VW 382/7

NOTE:

New piston/cylinder allocations are shown by a colored mark on the piston
crown.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 63: Identifying VW 382/7
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VW 385/17



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 64: Identifying VW 385/17
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test sequence

Piston projection at TDC must be measured when installing new pistons or a short block. Depending upon
piston projection, install the corresponding cylinder head gasket using the following table:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
