Volkswagen New Beetle. Manual - part 1065





z

T10020 Two hole pin wrench

Fig. 81: Identifying T10020 Two Hole Pin Wrench
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installed position

z

Angled retainer (arrow) must locate in cutout on cylinder head.

Fig. 82: Locating Semi-Automatic Toothed Belt Tensioning Roller Angled Retainer
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirements

z

Engine must only be hand touch warm.

Work sequence

z

Set engine to TDC No. 1 cylinder.

z

Press hard with thumb on toothed belt. Indicator -2- must move.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 83: Tensioning Toothed Belt
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Release thumb pressure on toothed belt and turn crankshaft two turns in engine direction of rotation until
engine is again at TDC No. 1 cylinder. Last 45° (1/8 turn) must be performed without stopping.

Tensioning roller must return to its original position (notch -1- and indicator -2- are again aligned).

Cylinder head, removing and installing

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

V.A.G 1306 Drip tray

z

V.A.G 1332 Torque wrench (40...200 N.m)

z

VAS 5024 Assembly tool for spring-type clips

z

3450/2A Guide pins

z

3450/3 Removal tool

z

3452 Key

Fig. 84: Identifying Special Tools
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

Use a mirror when checking.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

T10112 Installation tool

Fig. 85: Identifying T10112 Installation Tool
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirements

z

Engine must only be hand touch warm.

Work sequence

z

With ignition switched off disconnect battery Ground strap.

z

Remove engine cover.

z

Drain coolant. See COOLING SYSTEM, DRAINING AND FILLING .

z

Observe rules for cleanliness. See RULES FOR CLEANLINESS .

CAUTION: When performing repair work, especially due to the confined conditions in

the engine compartment, pay attention to the following:

z

Route all types of lines (e.g. for fuel, hydraulics, EVAP system,
coolant, refrigerant, brake fluid and vacuum) as well as electrical
wiring so that the original positions are restored.

z

Ensure sufficient clearance to all moving or hot components.

NOTE:

During the further course of work the battery Ground strap must be
disconnected. Therefore, please check whether a coded radio is installed.
Obtain the radio code first if necessary.

WARNING:

z

Fire Hazard! Do NOT have anything in the area that can ignite
fuel!

z

Fuel system is under pressure! Before opening the system



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Engine codes AEG, AVH, AZG

z

Pull fuel supply line -3-, fuel return line -2- and vacuum line -1- off at connecting point.

Fig. 86: Removing Fuel Supply Line, Fuel Return Line And Vacuum Line (Engine codes AEG,
AVH, AZG)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect hose from EVAP canister purge regulator valve -N80-.

z

Disconnect fuel supply line -1- and fuel return line -2- from fuel rail and collect fuel that leaks out with a
clean cloth.

Fig. 87: Disconnecting Fuel Supply Line And Fuel Return Line From Fuel Rail (Engine Codes
AEG, AVH, AZG)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine code BDC

z

Disconnect fuel supply line -1- and fuel return line -2- at connection point on fuel rail.

place a cloth around the connection. Then release pressure by
carefully loosening the connection.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
