Fig. 107: Applying Silicone Sealing Bead On Oil Pan (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tighten oil pan bolts to 15 N.m (11 ft lb).

z

Tighten oil pan/transmission bolts to 45 N.m (33 ft lb).

Oil pressure and oil pressure switch, checking

Special tools and equipment

z

VAG 1342 Oil pressure gauge

NOTE:

z

After installing the oil pan, allow the sealant to dry for approx. 30
minutes before adding engine oil.

z

Assembly is the reverse of the disassembly sequence.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

VAG 1527 B Voltage tester

z

VW 1594 adapter kit

Fig. 108: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test sequence

z

Remove oil pressure switch -F1- and screw into tester.

NOTE:

Functional check and servicing the optical and acoustic oil pressure
warning:
See appropriate WIRING DIAGRAM article



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 109: Checking Oil Pressure Switch
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Screw tester into filter bracket in place of pressure switch.

z

Connect brown tester wire to Ground.

z

Connect VAG 1527B Voltage tester between battery Plus and oil pressure switch using jumper wires
from VW 1594 adapter kit.

If LED lights up:

z

Replace oil pressure switch -F1-.

If LED does not light up:

z

Start engine and slowly increase engine speed.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



At 0.75 to 1.05 bar, LED must light up. If not replace oil pressure switch -F1-.

z

Increase engine speed further.

At 2000 RPM and an oil temperature of 80°C, oil pressure must be 2.0 bar minimum.

NOTE:

At higher engine speeds, oil pressure must not exceed 7.0 bar. If
necessary replace oil pump cover complete with pressure relief valve.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
