ENGINE - LUBRICATION

LUBRICATION SYSTEM COMPONENTS, REMOVING AND INSTALLING

Oil pressure, checking. See OIL PRESSURE AND OIL PRESSURE SWITCH, CHECKING .

Oil capacity up to MY 2000

z

With oil filter 4.5 liters (4.75 quarts)

Oil capacity from MY 2001

See maintenance guide with owner's manual.

Engine oil specifications:

The following terms must appear on the oil container singly or in combination with other designations:

z

VW 505 00

z

ACEA B3 or ACEA B4

z

API Service CF4 or API Service CG4

z

Engine oils are graded according to their viscosity. The proper grade to be used in your engine depends
on existing climatic or seasonal conditions.

z

The engine oil which was first put into your engine has a viscosity grade of SAE 5W-40. You can use this
oil over all temperature ranges for normal driving. If engine oil viscosity grade SAE 5W-40 is not
available, you can also use SAE 5W-30.

Part I

Oil filter bracket, disassembling. See PART II

installed. Hydraulic compensation elements must settle or the valves will
strike the pistons.

NOTE:

z

If large quantities of metal particles or other deposits (caused, for
example, by partial seizure of the crankshaft or conrod bearings) are found
in the engine oil when performing repairs, clean the oil passages
thoroughly and replace the oil cooler (mandatory) to prevent future
damage.

z

The oil level must NOT be above the MAX. mark-there is the possible
danger of damaging the catalyst!

NOTE:

The following list refers to items in Fig. 102 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



1. Oil pump

z

12 bar pressure relief

z

Make sure both centering dowels are installed

z

Replace if any running surfaces or gears are scored

2. Chain sprocket

3. N.m (18 ft lb)

4. Chain

5. Sealing flange

z

Removing and installing: See SEALING FLANGE (FRONT), REMOVING AND
INSTALLING
 .

z

Insert with silicone sealant D 176 404 A2. See SEALING FLANGE (FRONT), REMOVING
AND INSTALLING
 .

z

Crankshaft oil seal, replacing (pulley side). See SEALING RING (CRANKSHAFT PULLEY
SIDE), REPLACING
 .

6. 15 N.m (11 ft lb)

7. Chain tensioner (with tensioning rail)

z

15 N.m (11 ft lb)

z

To install, first pretension spring

8. Dipstick

z

Oil level must NOT be above the MAX. mark!

z

Marks: See Dipstick, markings

9. Guide

z

Remove to draw out oil

10. Guide tube

11. Centering dowels

12. O-ring

z

Always replace

13. Suction pipe

z

Clean strainer if soiled

14. Baffle plate

15. Oil pan

z

Clean sealing surfaces before installing

z

Install with silicone sealant D 176 404 A2. See OIL PAN, REMOVING AND INSTALLING

16. Seal

z

Integral with oil drain plug

17. Oil drain plug

z

30 N.m (22 ft lb)

z

Replace if leaking. See Parts Catalog for correct application. In some cases, seal and drain plug are



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



combined; do not interchange with separate seal and drain plug.

Fig. 102: Exploded View Of Lubrication System Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Part II

1. Sealing plug

z

25 N.m (18 ft lb)

2. Gasket

z

Always replace

3. Oil cooler

z

Make sure clearance between adjacent components

z

See note. See LUBRICATION SYSTEM COMPONENTS, REMOVING AND INSTALLING

4. Gasket

z

Always replace

z

Install into oil cooler groove

5. Seal

z

If seal leaks, nip open and replace.

6. Plug

z

10 N.m (7 ft lb)

7. Sealing plug

z

Do NOT open

8. Spring

z

For pressure relief valve, approx. 5 bar

9. Piston

z

For pressure relief valve, approx. 5 bar

10. 0.9 bar oil pressure switch -F1-

z

25 N.m (18 ft lb)

z

Gray

z

Checking: See OIL PRESSURE AND OIL PRESSURE SWITCH, CHECKING

11. Gasket

z

Always replace

12. 15 N.m (11 ft lb) plus additional1/4 turn (90°)

z

Always replace

z

Place bolts first top left and right, then tighten all four bolts over cross

13. Oil filter bracket

14. Seal

z

Always replace

15. Oil supply pipe

z

To the turbocharger

NOTE:

The following list refers to items in Fig. 103 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
