Volkswagen New Beetle. Manual - part 1011





Fig. 14: Installing Sound Dampening Tray
Courtesy of VOLKSWAGEN OF AMERICA, INC.

See NOISE INSULATION, ASSEMBLY OVERVIEW .

z

Fill with engine coolant. See COOLING SYSTEM, DRAINING AND FILLING .

Tightening torques

TIGHTENING TORQUE CHART - ENGINE REMOVAL & INSTALLATION

Engine and transmission assembly, mountings

Tightening torques

Bolted joint

Metric Size

Tightening torque

Bolts, nuts

M 6

10 Nm

7 ft lb

M 8

25 Nm

18 ft lb

M10

40 Nm

30 ft lb

M 12

60 Nm

44 ft lb

Variations on the above:
Engine to transmission M12 connecting bolts

80 Nm

59 ft lb

Torque converter to drive plate

60 Nm

44 ft lb

Drive shaft to flange / transmission

40 Nm

30 ft lb

Front exhaust pipe to turbocharger

25 Nm

18 ft lb



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



FRONT ENGINE/TRANSMISSION MOUNT TIGHTENING TORQUE CHART

Fig. 15: Identifying Front Engine/Transmission Mount
Courtesy of VOLKSWAGEN OF AMERICA, INC.

RIGHT REAR ENGINE/TRANSMISSION MOUNT TIGHTENING TORQUE CHART

NOTE:

The FRONT ENGINE/TRANSMISSION MOUNT TIGHTENING TORQUE CHART
table refers to items in Fig. 15 .

Application

Specfication

1 - Mount to body

(1)

40 Nm (30 ft lb) + 90° (1/4 turn.)

2 - Mount/bracket to body

25 Nm (18 ft lb)

3 - Mount to engine bracket

(1)

60 Nm (44 ft lb) + 90° (1/4 turn.)

(1)

Replace bolts

NOTE:

The RIGHT REAR ENGINE/TRANSMISSION MOUNT TIGHTENING TORQUE
CHART table refers to items in Fig. 16 .

Application

Specification

1 - Mount to body

(1)

40 Nm (30 ft lb) + 90° (1/4 turn.)

2 - Mount to body

25 Nm (18 ft lb)

3 - Mount to transmisison console

(1)

60 Nm (44 ft lb) + 90° (1/4 turn.)

(1)

Replace bolts



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 16: Identifying Right Rear Engine/Transmission Mount
Courtesy of VOLKSWAGEN OF AMERICA, INC.

PENDULUM SUPPORT TIGHTENING TORQUE CHART

Fig. 17: Identifying Pendulum Support
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with A/C, additional information and removal instructions

NOTE:

The PENDULUM SUPPORT TIGHTENING TORQUE CHART table refers to items
in Fig. 17 .

Application

Specification

1 - Pendulum support to transmission

(1)

40 Nm (30 ft lb) + 90° (1/4 turn.)

2 - Pendulum support to transmission

(1)

40 Nm (30 ft lb)+ 90° (1/4 turn.)

3 - Pendulum support to engine

(1)

20 Nm (15 ft lb) + 90° (1/4 turn.)

(1)

Replace bolts



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



To ease engine removal and installation without opening the A/C refrigerant circuit:

z

Remove retaining clamp(s) from refrigerant lines.

z

Remove A/C compressor:

See A/C REFRIGERANT SYSTEM, SERVICING , item 13.

z

Attach A/C compressor to vehicle body to provide stress relief for refrigerant lines/hoses.

Fig. 18: Attaching A/C Compressor To Vehicle Body
Courtesy of VOLKSWAGEN OF AMERICA, INC.

ENGINE - CRANKSHAFT, CYLINDER BLOCK

ENGINE, DISASSEMBLING AND ASSEMBLING

WARNING:

Do NOT open the A/C refrigerant circuit.

NOTE:

To prevent damage to the condenser and to the refrigerant lines/hoses, make
sure that the lines and hoses are not stretched, kinked or bent.

NOTE:

z

If during repairs, metal shavings or quantities of small metal particles are
found in the engine oil - caused, for example, by partial seizure of the
crankshaft and conrod bearings - then, besides thoroughly cleaning out
the oil passages, also replace the oil cooler.

z

Faulty injectors can cause violent knocking noises in the engine which
sound like faulty bearings. When this occurs, run engine at idle and
slacken off the injector line unions one after the other. If the knocking
stops when a specific union is loosened, this is an indication that the



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
