Fig. 4: Disconnecting Fuel Supply And Return Lines
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Seal off lines so fuel system is not contaminated by dirt etc.

Vehicles with manual transmission

z

Disconnect selector mechanism from transmission.

See SELECTOR MECHANISM ON TRANSMISSION SIDE, UP TO 5.99 DISASSEMBLING AND
ASSEMBLING
 or SELECTOR MECHANISM ON TRANSMISSION SIDE, AS OF 6.99
DISASSEMBLING AND ASSEMBLING
 .

z

Remove hydraulic clutch slave cylinder:

See CLUTCH SLAVE CYLINDER

Vehicles with automatic transmission

z

Remove Transmission Range selector lever cable from transmission:

See SELECTOR LEVER CABLE

All vehicles

z

Remove sound dampening tray:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 5: Removing Sound Dampening Tray
Courtesy of VOLKSWAGEN OF AMERICA, INC.

See NOISE INSULATION, ASSEMBLY OVERVIEW

z

Drain engine coolant. See COOLING SYSTEM, DRAINING AND FILLING

z

Remove line between charge air cooler and turbocharger.

z

Pull radiator hoses off engine using VAG 1921 hose clip pliers.

z

Remove lower coolant hose from radiator.

z

Remove auxiliary filter, if available, on right side of vehicle.

z

Loosely unscrew pendulum support (arrows).

Fig. 6: Removing Pendulum Support Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull vacuum and breather hoses off engine.

z

Disconnect all wiring from the transmission, Generator and starter and move them to one side for
clearance.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Remove front exhaust pipe. See FRONT EXHAUST PIPE AND CATALYST WITH
ATTACHMENTS


z

Remove ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING .

z

Remove power steering pump with bracket and lay to one side.

z

Hoses remain connected:

See POWER STEERING PUMP, RESERVOIR, HYDRAULIC LINES .

z

Remove right hand inner Constant Velocity joint protective cover from engine if installed.

z

Remove right-hand drive shaft and disconnect left-hand drive shaft at transmission:

See FRONT AXLE SHAFT .

z

Unscrew mounting bolts for power steering pressure line.

Vehicles with A/C:

z

Observe additional information and removal instructions. See VEHICLES WITH A/C, ADDITIONAL
INFORMATION AND REMOVAL INSTRUCTIONS
 .

z

Remove starter.

See appropriate STARTERS article.

All vehicles:

z

Insert engine bracket 3396 into VAG 1383 A engine / transmission jack.

z

Remove coolant hose bracket and lower from cylinder block.

z

Thread hole is used to fasten T 10012 engine bracket

z

Thread on T 10012 engine bracket using M10x 25 5/ 8.8 nut and bolt.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 7: Threading On T 10012 Engine Bracket
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Attach to engine block with 25 Nm (18 ft lb)

z

Slightly lift engine/transmission assembly using VAG 1383 A jack.

z

Loosely unscrew engine mount (engine side) from top of engine bracket (arrows).

Fig. 8: Removing Engine Mount Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Loosely unscrew engine mount/transmission mount from transmission bracket (arrows) from top.

Fig. 9: Removing Engine Mount/Transmission Mount Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Carefully lower engine/transmission assembly.

NOTE:

Use VAS 5085 tool to remove the mounting bolts.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
