Volkswagen New Beetle. Manual - part 1002





Fig. 116: Removing Valve Stem Seals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 117: Inserting Valve Stem Seal Into Installation Tool
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Place plastic sleeve -A- supplied on appropriate valve stem. This will prevent new valve stem seal -B-
from being damaged.

z

Insert new valve stem seal into installation tool 3129.

z

Oil valve stem seal sealing lip and press carefully onto valve guide.

Camshaft, removing and installing

Special tools and equipment

z

T10051 Counterhold

z

T10052 Puller

z

V.A.G1331 Torque wrench (5 to 50 N.m)

z

V.A.G 1332 Torque wrench (40 to 200 N.m)

z

Sealant AMV 174 004 01



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 118: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove toothed belt. See TOOTHED BELT, REMOVING AND INSTALLING .

z

Remove camshaft gear securing bolts -1-.

Fig. 119: Removing Camshaft Gear Securing Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove camshaft gear from hub.

z

Using counterhold T10051, loosen camshaft pulley securing bolt -1- from hub.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 120: Loosening Camshaft Pulley Securing Bolt
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unscrew hub securing bolt approx. 2 turns.

z

Position puller T10052 and thread bolts -1- into hub.

z

Pull hub off by counter-holding puller with a wrench (30 mm) and turning bolt -2-.

Fig. 121: Removing Hub Using Puller T10052
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove cylinder head cover. See CYLINDER HEAD COVER, REMOVING AND INSTALLING .

z

Mark rocker shafts with a waterproof felt-tipped pen to avoid interchanging and therefore disrupting
injection pump basic setting (arrows).

z

Loosen exterior bolts -1- at rocker shaft first and then interior bolts -2-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)
