that it can be slid out of the ball head mounting -2- in -direction of arrow- to the rear. – Take the right headlight range control motor -V49- out of the headlight as far as the connected wiring allows. – Disconnect connector -1- and remove right headlight range control motor -V49- -2-. Installing ing: – Reconnect connector -1- on right headlight range control mo‐ tor -V49- -2-. – Insert right headlight range control motor -V49- -1- in headlight in position as shown in illustration. – Lift dipped beam reflector in headlight slightly and turn the ball head of the right headlight range control motor -V49- -2- so that it can be pushed into the ball head mounting -3- in -direction of arrow-. 226
|
