Horn 10.1 Removing and installing treble horn - H2- / bass horn -H7- The treble horn -H2- / bass horn -H7- are actuated in parallel by the onboard supply control unit -J519- . next to the longitudinal members. same way. Caution ♦ Switch off ignition and all electrical consumers. Removing Rep. gr. 50 . – Disconnect connector -arrow-. – Remove screw -arrow- and take out treble horn -H2- . Note When installing, position the horn so it is not in contact with ad‐ jacent components. – Tighten bracket bolt on longitudinal member to 20 Nm. 10.2 Checking treble horn -H2- / bass horn - H7- Treble horn -H2- / bass horn -H7- can be checked in final control diagnosis of onboard supply control unit -J519- . 438 |
