Removing and installing steering col‐ umn switch base Note To remove the steering column switch base -2-, the shear bolts of the steering lock housing must be drilled out. To reinstall, new shear-head bolts -1- are required ⇒ Parts catalogue (ETKA) . Caution ♦ Ensure that the components mounted on the carrier have been removed before drilling out the shear-head bolts. ♦ The drilling operation can cause swarf to penetrate the adjacent components resulting in damage and/or mal‐ function! ♦ Keep to the specified sequence when removing compo‐ nents. ♦ When battery -A- is disconnected and reconnected, the procedure described in the workshop manual must be Removing . gr. 69 . – Remove steering column trim ⇒ General body repairs, interior; Rep. gr. 68 . – Remove steering column electronics control unit -J527- . – Remove airbag coil connector and return ring with slip ring - – Remove steering angle sender -G85- . – Remove turn signal light switch -E2- – Remove windscreen wiper switch -E- 326 |
