Alternator -C- 2.0l TSI engine 7.17.1 Assembly overview 1 - Hexagon head flange bolt ❑ 20 Nm 2 - Cross-head screws ❑ 2 Nm 3 - Washer ❑ 4.5 Nm 5 - Hexagon nut ❑ 15 Nm 6 - Hexagon nut -C- ❑ 2 Nm 9 - Voltage regulator -C1- ❑ Removing and installing 10 - Alternator -C- ❑ Removing and installing ❑ Checking ❑ Securing battery posi‐ ❑ Removing and installing poly V-belt pulley 11 - Poly V-belt ❑ Removing and installing ⇒ Engine; Rep. gr. 13 ❑ Checking ❑ Poly V-belt routing ⇒ Engine; Rep. gr. 13 13 158 |
