on both sides with a minimum of 20 mm -dimension x- of heat-

shrink sleeve.

– Slide the heat-shrink tubing over the corrugated tube, attach

the connecting pieces together and secure the repair area with

heat-shrink tubing.

Beetle 2012 ➤ , Golf 2015 ➤ , Golf Variant 2007 ➤ , Golf Variant 2010 ➤ ...

76

Joint-Free Wiper Blade Characteris‐

tics

⇒ “2.1 Joint-Free Wiper Blade Characteristics”, page 77

2.1

Joint-Free Wiper Blade Characteristics

Characteristics for Bosch and Federal Mogul
Check the manufacturer when replacing the wiper blades. Always

replace them with blades made by the same manufacturer.
The wiper blades can be identified by the wiper arm mount.
Bosch Wiper Blades -1 and 2-:

Federal Mogul Wiper Blades -1-:

Beetle 2012 ➤ , Golf 2015 ➤ , Golf Variant 2007 ➤ , Golf Variant 2010 ➤ ...

2. Joint-Free Wiper Blade Characteristics

77

Special Tools

Special tools and workshop equipment required
♦ Hot Air Blower - VAS5179- or

Beetle 2012 ➤ , Golf 2015 ➤ , Golf Variant 2007 ➤ , Golf Variant 2010 ➤ ...

78

1

HID Headlamp Usage and Safety

Precautions

⇒ “1.1 Safety Precautions”, page 79

1.1

Safety Precautions

If Performing Assembly Work on HID Headlamps, Note the Fol‐

lowing
♦ Notes on hazardous high voltage/currents. Refer to

⇒ page 79

♦ Notes on pressure, temperature and radiation/electric arc. Re‐

fer to

⇒ page 80

♦ Assembly notes on HID headlamp bulbs. Refer to

⇒ page 81

♦ Disposal regulations for HID headlamp bulbs. Refer to

⇒ page 81

Special tools and workshop equipment required
♦ Protective eyewear
♦ Gloves

WARNING

Always disconnect the Battery - A- before working on any HID

headlamp components marked with the yellow high voltage

tery; Battery, Removing and Installing .
Then switch the low beams on and back off. This removes any

possible residual voltage.
The gas discharge lamp control module should not be operated

without the gas-discharge lamp.
Due to the high voltage (over 28000 V when igniting the lamp)

and temperatures, the HID headlamp bulb should only be op‐

erated inside the headlamp housing.

WARNING

♦ Never change an HID headlamp bulb if you are not familiar

with the corresponding steps, safety precautions and the

tool.

Warnings for Dangerous High Voltage and Currents

WARNING

Light system control modules, connectors or components in

the bulb socket area conduct dangerous high voltage
The control module and igniter may be used only on the HID

headlamp bulb.

Beetle 2012 ➤ , Golf 2015 ➤ , Golf Variant 2007 ➤ , Golf Variant 2010 ➤ ...

1. HID Headlamp Usage and Safety Precautions

79
