Golf/Golf Plus

Spark plug change intervals

1.8 TSI, 2.0 TSI; 2.0 TFSI

and V6 FSI

AXX, BPY, BWA, BYD, CAVD,

CAWB, CBFA, CBRA, CCTA

EVERY 90,000 km

• Mileage more than 90,000 km in 6 years

EVERY 6 years

• Mileage less than 90,000 km in 6 years

2.3

Delivery inspection

♦ The sequence of the individual service tasks has been tested

and optimised. Therefore, it should be followed to avoid un‐

necessary interruptions in the work.

♦ For stock vehicles and vehicles in storage perform service for

stock vehicles and vehicles in storage “Maintenance tables”.

Work to be completed

Page

– Battery: Check battery terminals by hand for tightness

page 45

– Battery: Check using battery tester with printer -VAS 5097A-

page 48

– Transportation mode: Switch off

page 141

– Service interval display: Reset

• Only valid for stock vehicles and vehicles in storage

page 126

– Reading radio code using vehicle diagnostic tester

page 114

– Radio/radio navigation system: Enter PIN of anti-theft coding and store local radio stations to

station buttons

page 115

– All switches, electrical consumers, gauges and other controls: Check function



– Clock: Set to correct time

page 144

– Front passenger front airbag: Check key switch and “On/Off function”, set switch to “On”.

page 63

– Electric windows: Check positioning (open and close functions)

page 61

– Calibrating compass (for North American region)

page 71

– Auxiliary heater: Set weekday in menu of combi-instrument

• Only valid for vehicles with auxiliary heater

page 140

– Check vehicle interior for cleanliness: Front and rear seats, interior trim, carpets/mats, win‐

dows



– Seat and carpet protective coverings: Remove



– Install all equipment (if any) which has been packed inside vehicle: mats, wheel trims or hub

caps.



– Edge protection on doors (plastic foil): Remove



– Check vehicle exterior for cleanliness: Paintwork, decorative parts, windows, wiper blades,

surfaces



– Wiper blade protection: Remove

page 137

– Wheel securing bolts: Tighten to prescribed torque setting

page 112

Maintenance - Edition 11.2009

14

    2. Service work

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

Work to be completed

Page

– Tyre inflation pressure of all 4 wheels and spare wheel: Set to correct pressures (in the factory

the tyres are inflated to 3.5 bar).

page 48

– Tyre pressure monitoring: Perform basic setting

page 116

– Optional equipment “Spare wheel package”: Check condition and inflation pressure.

page 48

– Vehicle from below, visual check for leaks and damage (without removing engine noise in‐

sulation cover): Engine, steering, protective bellows/boots, hoses and fluid reservoirs.

page 100

– Transport devices (vehicles with sports running gear): Remove blocking pieces from front axle

springs.

page 143

– Vehicle underside (floor pan): Perform visual check for damage

page 143

– Window wash/wipe system and headlight washer system: Check function and settings; re‐

plenish with Windscreen Clear -G 052 164- to maximum

page 131

– Engine oil level: Check, top-up with engine oil if necessary; observe oil specifications!

page 101

– Engine and components in engine compartment (from above): Perform visual check for leaks

and damage

page 100

– Coolant level: Check that it is at maximum

page 72

– Brake fluid: Check that it is at maximum

page 57

– “Your first service” sticker: Apply to driver side door pillar (B-pillar); sticker can be found on

an instruction attached at front of vehicle wallet. Destroy the instruction after attaching the

sticker!

page 30

– Long-life engine oil sticker: Apply to left side of lock carrier

• Applies to vehicles with long-life service and PR number QG1
Note: Gradual deletion from week 04/07

page 30

– Hotline sticker (if fitted, gradual deletion: Apply to the inside of glove box cover

• Only valid for Germany
Note: Gradual deletion

page 32

– Check number and functions of keys, if necessary remove grease



– Vehicle data sticker: Apply

page 30

♦ Service schedule:
– Enter delivery inspection and enter a cross for the first service:

♦ Interval service for vehicles with long-life service (PR No. QG1)

1)

♦ Oil change service for vehicles with time or distance dependent service (PR No. QG0/QG2)

1)

– Complete vehicle data in service schedule, see “Vehicle delivery documentation”



– Check literature for vehicle is complete and prepare literature for delivery to customer



– Perform road test (driving behaviour, noises, air conditioner etc.)

page 112

1)

 Service identification

⇒ page 7

Maintenance - Edition 11.2009

2. Service work

15

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

2.4

Oil change service

Note

The oil change service is always a time or distance dependent

service “QG0/QG2”

⇒ page 8

Inform the customer if faults are found during service and re‐

pair measures are necessary.

Caution

Only valid for diesel engines:

• In some countries the sulphur content in diesel fuel ex‐

ceeds 2000 ppm.

• The high sulphur content leads to excessive wear of cyl‐

inders and it considerably reduces the cleanliness of pis‐

tons.

♦ Therefore, in countries with elevated sulphur content in

diesel fuel, change engine oil and fuel filter every 7,500

km.

♦ Your importer will inform you about countries with elevated

sulphur content in diesel fuel.

– Ask the customer if he requires:
• New wiper blades
• Replenish Windscreen Clear G 052 164 (cleanser and anti-

freeze).

– Check if storage life date of first aid box has been exceeded

and if warning triangle is fitted.

– Removing and installing engine compartment cover -bottom-

(noise insulation tray)

⇒ page 99

The sequence of the individual service tasks has been tested and

optimised. Therefore, it should be followed to avoid unnecessary

interruptions in the work.

Work to be completed

Page

– Engine oil: Drain or extract

1

, renew oil filter

page 101

– Front and rear brake pads/linings: Check thickness

page 59

– Engine oil: Replenish, observe oil specification

page 101

– Service interval display: Reset

page 126

– Enter date of next service on sticker and attach sticker to driver side door pillar (B-pillar).

page 30

1) For the V6 engine it is not permitted to extract engine oil.

Maintenance - Edition 11.2009

16

    2. Service work

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

2.5

Interval service ▸2007

Note

The interval service is a time or distance dependent service

“QG0/QG2”

⇒ page 8

 and also a long-life service

⇒ page 7

The interval service always includes an engine oil change!

Additional type-specific tests ensure an extended oil change

service.

The prerequisites for the interval service with a running period

of max. 2 years or 30,000 km can only be fulfilled if engine oil

for long-life service is used or replenished.

Inform the customer if faults are found during service and re‐

pair measures are necessary.

Caution

Only valid for diesel engines:

• In some countries the sulphur content in diesel fuel ex‐

ceeds 2000 ppm.

• The high sulphur content leads to excessive wear of cyl‐

inders and it considerably reduces the cleanliness of pis‐

tons.

♦ Therefore, in countries with elevated sulphur content in

diesel fuel, change engine oil and fuel filter every 7,500

km.

♦ Your importer will inform you about countries with elevated

sulphur content in diesel fuel.

– Ask the customer if he requires:
• New wiper blades
• Replenish Windscreen Clear G 052 164 (cleanser and anti-

freeze).

– Check if storage life date of first aid box has been exceeded

and if warning triangle is fitted.

– Removing and installing engine compartment cover -bottom-

(noise insulation tray)

⇒ page 99

The sequence of the individual service tasks has been tested and

optimised. Therefore, it should be followed to avoid unnecessary

interruptions in the work.

Work to be completed

Page

– Battery: Check using battery tester with printer -VAS 5097A-

page 48

– Vehicle system test: Perform test

page 62

– Engine oil: Drain or extract

1

, renew oil filter

page 101

– Tyres (including spare wheel): Check tread depth, wear pattern and inflation pressure

page 48

– Tyre pressure monitoring: Perform basic setting

• If fitted

page 116

Maintenance - Edition 11.2009

2. Service work

17
