Toyota Auris (2018 year). Manual in english - page 11

658

9-1. Specifications

 16-inch and 17-inch tires

Tire size

205/55R16 91V, 215/45R17 87W, 225/45R17 91W

Front wheel

Rear wheel

2

Vehicle speed

kPa

(kgf/cm

kPa

(kgf/cm²

Tire inflation pres-

or bar, psi)

or bar, psi)

sure

(Recommended

More than 160

260 (2.6, 38)

260 (2.6, 38)

cold tire inflation

km/h (100 mph)

pressure)

160 km/h

(100

230 (2.3, 33)

230 (2.3, 33)

mph) or less

16  6 1/2 J (16-inch tires),

Wheel size

17  7 J (17-inch tires)

Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

 Compact spare tire

Tire size

T125/70D17 98M

Tire inflation pressure

(Recommended cold

420 kPa (4.2 kgf/cm² or bar, 60 psi)

tire inflation pressure)

Wheel size

17  4 T

Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

■ When towing a trailer

Add 20.0 kPa (0.2 kgf/cm² or bar, 3 psi) to the recommended tire inflation

pressure and drive at speeds below 100 km/h (62 mph).

9-1. Specifications

659

Light bulbs

Light Bulbs

W

Type

Halogen headlights*

55

A

Front fog lights*

19

B

Front turn signal lights

21

C

Side turn signal lights

5

C

Exterior

Rear turn signal lights

21

D

Stop lights

21

E

Back-up light

16

F

Licence plate lights

5

F

Vanity lights*

5

G

Front interior lights/personal lights

8

F

Interior

Rear interior light*

8

G

Rear personal lights*

8

F

Luggage compartment light

5

G

A: HIR2 halogen bulbs

B: H16 halogen bulbs

C: Wedge base bulbs (amber)

D: Single end bulbs (amber)

E: Single end bulbs (clear)

F: Wedge base bulbs (clear)

G: Double end bulbs

*: If equipped

9

660

9-1. Specifications

Fuel information

 Gasoline engine

When you find these types of fuel label at the gas station, use

only the fuel with one of the following labels.

EU area:

You must only use unleaded gasoline conforming to European

standard EN228.

Select unleaded gasoline with a Research Octane Number of 95

or higher for optimum engine performance.

Except EU area:

You must only use unleaded gasoline.

Select unleaded gasoline with a Research Octane Number of 95

or higher for optimum engine performance.

9-1. Specifications

661

 Diesel engine

When you find these types of fuel label at the gas station, use

only the fuel with one of the following labels.

For 1WW engine

Except for 1WW engine

EU area:

You must use diesel fuel conforming to European standard

EN590 or EN16734.

Except EU area:

You must use only diesel fuel that contains 50 ppm or less of

sulfur with a cetane number of 48 or higher.

Ultra low sulfur diesel max 10 ppm

■ Use of ethanol blended gasoline in a gasoline engine

Toyota allows the use of ethanol blended gasoline where the ethanol content

is up to 10%. Make sure that the ethanol blended gasoline to be used has a

Research Octane Number that follows the above.

■ If you plan to drive in foreign countries (diesel engine)

Low sulfur diesel fuel may not be available, so please check the availability

with your distributor.

■ If your engine knocks

9

●Consult any authorized Toyota dealer or repairer, or another duly qualified

and equipped professional.

● You may occasionally notice light knocking for a short time while accelerat-

ing or driving uphill. This is normal and there is no need for concern.

9-2. Customization

663

Customizable features

Your vehicle includes a variety of electronic features that can be

personalized to your preferences. The settings of these features

can be changed using the meter control switches, on the naviga-

tion/multimedia system screen or at any authorized Toyota

dealer or repairer, or another duly qualified and equipped pro-

fessional.

Customizing vehicle features

■ Changing on the navigation/multimedia system screen (vehi-

cles with a navigation/multimedia system)

1

Press the “SETUP” button.

2

Touch “Vehicle” on the “Setup” screen.

Select the desired item.

Various settings can be changed. Refer to the list of settings that

can be changed for details.

■ Changing using the meter control switches (vehicles with a 2-

ring meter)

P. 122

Customizable features

Some function settings are changed simultaneously with other func-

tions when customized. Contact any authorized Toyota dealer or

repairer, or another duly qualified and equipped professional for fur-

ther details.

1

Settings that can be changed on the navigation/multimedia system

9

screen (vehicles with a navigation/multimedia system)

Settings that can be changed using the meter control switches

2

(vehicles with a 2-ring meter)

Settings that can be changed by any authorized Toyota dealer or

3

repairer, or another duly qualified and equipped professional

Definition of symbols: O = Available, — = Not available

664

9-2. Customization

■ Gauges, meters and multi-information display*¹ (P. 110, 119)

Customized set-

Function*²

Default setting

ting

1

2

3

*4

Language*³

English

—

O

—

km (km/L)

km (L/100 km)

O

O

—

Units*³

miles (MPG)

°C

°F

O

O

—

Eco Driving Indicator

On

Off

—

O

—

Light*⁵

(Self-lighting)

Current fuel

consumption

(gauge display)

*6

Drive information 1

—

O

—

Average fuel

economy (after

reset)

Distance

(driving range)

*6

Drive information 2

—

O

—

Average vehi-

cle speed (after

reset)

Stop & Start

system opera-

tion time (after

start)

*6

Drive information 3*⁵

—

O

—

Stop & Start

system opera-

tion time (after

reset)

Pop-up display*⁵

On

Off

—

O

—

9-2. Customization

665

^*1: Vehicles with a 2-ring meter

^*2: For details about each function: P. 125

^*3: The default setting varies according to country.

^*4: German, French, Spanish, Italian, Portuguese, Dutch, Swedish, Norwe-

gian, Danish, Russian, Finnish, Greek, Polish, Ukrainian, Turkish, Hungar-

ian, Czech, Slovak, Romanian

^*5: If equipped

^*6: 2 of the following items: current fuel consumption (gauge display), current

fuel consumption (numerical display), average fuel economy (after reset),

average fuel economy (after start), average fuel economy (after refuel),

Stop & Start system operation time (after reset)*⁵, Stop & Start system

operation time (after start)*⁵, average vehicle speed (after reset), average

vehicle speed (after start), elapsed time (after reset), elapsed time (after

start), distance (driving range), distance (after start), blank.

■ Smart entry & start system*¹ and wireless remote control

(P. 146, 152, 157)

Customized set-

Function

Default setting

1

2

3

ting

Operation signal

On

Off

O

—

O

(Emergency flashers)

Time elapsed before

60 seconds

automatic door lock func-

tion is activated if door is

30 seconds

—

—

O

120 seconds

not opened after being

unlocked

Open door warning

On

Off

—

—

O

buzzer*²

^*1: If equipped

^*2: Vehicles with a smart entry & start system

9

666

9-2. Customization

■ Smart entry & start system*¹ (P. 146, 152, 157)

Customized set-

Function

Default setting

ting

1

2

3

Smart entry & start sys-

On

Off

O

—

O

tem

Number of consecutive

As many as

2 times

—

—

O

door lock operations*²

desired

^*1: If equipped

^*2: Left-hand drive vehicles

■ Wireless remote control (P. 134, 146, 152)

Customized set-

Function

Default setting

1

2

3

ting

Wireless remote control

On

Off

—

—

O

Push twice

Press and hold

(short)

Back door unlocking

One short

—

—

O

operation*

press

Press and hold

(long)

Off

*: If equipped

■ Turn signal lever (P. 258)

Customized set-

Function

Default setting

1

2

3

ting

The number of times the

5

turn signal lights flash

7

automatically when the

3

—

—

O

turn signal lever is moved

to the first position during

Off

a lane change

9-2. Customization

667

■ Automatic light control system* (P. 260)

Customized set-

Function

Default setting

ting

1

2

3

Light sensor sensitivity

Standard

-2 to 2

O

—

O

*: If equipped

■ Follow me home system (P. 262)

Customized set-

Function

Default setting

ting

1

2

3

60 seconds

Time elapsed before

headlights automatically

30 seconds

90 seconds

—

—

O

turn off

120 seconds

■ LDA (Lane Departure Alert)* (P. 296)

Customized set-

Function

Default setting

ting

1

2

3

LDA warning sensitivity

High

Standard

—

O

—

*: If equipped

■ RSA (Road Sign Assist)* (P. 305)

Customized set-

Function

Default setting

ting

1

2

3

RSA system

On

Off

—

O

—

Display and

Notification method of

buzzer

Only display

—

O

—

excessive speed

Off

Display and

9

Notification

methods

buzzer

other than excessive

Only display

—

O

—

speed

Off

10 km/h (5 mph)

Notification

level

of

2 km/h (1 mph)

—

O

—

excessive speed

5 km/h (3 mph)

*: If equipped

668

9-2. Customization

■ Stop & Start system* (P. 311)

Customized set-

Function

Default setting

ting

1

2

3

Change the Stop & Start

system duration when the

Normal

Long

—

O

—

A/C is on

*: If equipped

■ Toyota parking assist-sensor*¹ (P. 333)

Customized set-

Function

Default setting

ting

1

2

3

Toyota parking assist-

On

Off

—

O

—

sensor system

Detection distance of the

Far

Near

O

—

O

front center sensors*²

Detection distance of the

Far

Near

O

—

O

rear center sensors*²

Buzzer volume*²

5

1 to 4

O

—

O

All sensors dis-

Display setting*^{2, 3}

Display off

O

—

O

played

^*1: If equipped

^*2: Vehicles with a navigation/multimedia system

^*3: When Toyota parking assist-sensor is operating.

■ Automatic air conditioning system* (P. 435)

Customized set-

Function

Default setting

ting

1

2

3

Switching between out-

side air and recirculated

On

Off

O

—

O

air

mode linked to

“AUTO” switch operation

A/C auto switch operation

On

Off

—

—

O

*: If equipped

9-2. Customization

669

■ Illumination (P. 447)

Customized set-

Function

Default setting

ting

1

2

3

Interior light illumination

On

Off

O

—

O

control*

7.5 seconds

Time elapsed before the

15 seconds

O*

—

O

interior lights turn off

30 seconds

Operation

after

the

engine switch is turned

On

Off

—

—

O

off

Operation when the

On

Off

—

—

O

doors are unlocked

Operation when you

approach the vehicle with

On

Off

—

—

O

the electronic key on your

person*

*: If equipped

■ Vehicle customization

When the doors remain closed after unlocking the doors and the timer acti-

vated automatic door lock function activates, signals will be generated in

accordance with the operational signal (emergency flashers) function setting.

WARNING

■ During customization

As the engine needs to be running during customization, ensure that the

vehicle is parked in a place with adequate ventilation. In a closed area such

as a garage, exhaust gases including harmful carbon monoxide (CO) may

collect and enter the vehicle. This may lead to death or a serious health

hazard.

9

NOTICE

■ During customization

To prevent battery discharge, ensure that the engine is running while cus-

tomizing features.

670

9-3. Initialization

Items to initialize

The following item must be initialized for normal system opera-

tion after such cases as the battery being reconnected, or main-

tenance being performed on the vehicle:

Item

When to initialize

Reference

• When rotating front and rear

tires which have different tire

inflation pressures

Tire pressure warning sys-

• When changing the tire size

P. 512

tem*

• When changing the tire infla-

tion pressure by changing

traveling speed or load

weight, etc.

*: If equipped

672

What to do if... (Troubleshooting)

What to do if... (Troubleshooting)

If you have a problem, check the following before contacting any

authorized Toyota dealer or repairer, or another duly qualified

and equipped professional.

The doors cannot be locked, unlocked, opened or closed

You lose your keys

● If you lose your keys or mechanical keys, new genuine keys or mechanical

keys can be made by any authorized Toyota dealer or repairer, or another

duly qualified and equipped professional. (P. 136)

● If you lose your keys or electronic keys, the risk of vehicle theft increases

significantly. Contact any authorized Toyota dealer or repairer, or another

duly qualified and equipped professional immediately. (P. 145)

The doors cannot be locked or unlocked

● Is the key battery weak or depleted? (P. 534)

● Vehicles with a smart entry & start system:

Is the engine switch in IGNITION ON mode?

When locking the doors, turn the engine switch off. (P. 241)

● Vehicles with a smart entry & start system:

Is the electronic key left inside the vehicle?

When locking the doors, make sure that you have the electronic key on

your person.

● The function may not operate properly due to the condition of the radio

wave. (P. 137, 161)

The rear door cannot be opened

● Is the child-protector lock set?

The rear door cannot be opened from inside the vehicle when the lock is

set. Open the rear door from outside and then unlock the child-protector

lock. (P. 150)

What to do if... (Troubleshooting)

673

If you think something is wrong

The engine does not start (vehicles without a smart entry &

start system)

● Vehicles with a manual transmission:

Do you turn the key with the clutch pedal depressed firmly? (P. 234)

● Vehicles with a Multidrive:

Is the shift lever in P? (P. 234)

● Is the steering wheel unlocked? (P. 235)

● Is the battery discharged? (P. 622)

The engine does not start (vehicles with a smart entry &

start system)

● Vehicles with a Multidrive:

Did you press the engine switch while firmly depressing the brake pedal?

(P. 238)

● Vehicles with a manual transmission:

Did you press the engine switch while firmly depressing the clutch pedal?

(P. 238)

● Vehicles with a Multidrive:

Is the shift lever in P? (P. 244)

● Is the electronic key anywhere detectable inside the vehicle? (P. 158)

● Is the steering wheel unlocked? (P. 245)

● Is the electronic key battery weak or depleted?

In this case, the engine can be started in a temporary way. (P. 620)

● Is the battery discharged? (P. 622)

674

What to do if... (Troubleshooting)

The shift lever cannot be shifted from P even if you depress

the brake pedal (vehicles with a Multidrive)

● Vehicles without a smart entry & start system:

Is the engine switch in the “ON” position?

If you cannot release the shift lever by depressing the brake pedal with the

engine switch in the “ON” position. (P. 253)

● Vehicles with a smart entry & start system:

Is the engine switch in IGNITION ON mode?

If you cannot release the shift lever by depressing the brake pedal with the

engine switch in IGNITION ON mode. (P. 253)

The steering wheel cannot be turned after the engine is

stopped

● Vehicles without a smart entry & start system:

It is locked to prevent theft of the vehicle if the key is pulled from the engine

switch. (P. 236)

● Vehicles with a smart entry & start system:

It is locked automatically to prevent theft of the vehicle. (P. 244)

The windows do not open or close by operating the power

window switches

● Is the window lock switch pressed?

The power window except for the one at the driver’s seat cannot be oper-

ated if the window lock switch is pressed. (P. 206)

The engine switch is turned off automatically (vehicles with

a smart entry & start system)

● The auto power off function will be operated if the vehicle is left in ACCES-

SORY or IGNITION ON mode (the engine is not running) for a period of

time. (P. 244)

What to do if... (Troubleshooting)

675

A warning buzzer sounds during driving

● The seat belt reminder light is flashing

Are the driver and the front passenger wearing the seat belts? (P. 573)

● The brake system warning light (red indicator) is on

Is the parking brake released? (P. 259)

Depending on the situation, other types of warning buzzer may also sound.

(P. 569, 581)

An alarm is activated and the horn sounds

(vehicles with an alarm)

● Did anyone inside the vehicle open a door during setting the alarm?

The sensor detects them and the alarm sounds. (P. 99)

Vehicles without a smart entry & start system:

To stop the alarm, turn the engine switch to the “ON” position or start the

engine.

Vehicles with a smart entry & start system:

To stop the alarm, turn the engine switch to IGNITION ON mode or start

the engine.

A warning buzzer sounds when leaving the vehicle

(vehicles with a smart entry & start system)

● Is the electronic key left inside the vehicle?

Vehicles with a 2-ring meter: Check the message on the multi-information

display. (P. 581)

A warning light turns on

(vehicles with a 3-ring meter)

● When a warning light turns on, refer to P. 569.

676

What to do if... (Troubleshooting)

A warning light turns on or a warning message is displayed

(vehicles with a 2-ring meter)

● When a warning light turns on or a warning message is displayed, refer to

P. 569, 581.

When a problem has occurred

If you have a flat tire

● Vehicles with a spare tire:

Stop the vehicle in a safe place and replace the flat tire with the spare tire.

(P. 587)

● Vehicles with an emergency tire puncture repair kit:

Stop the vehicle in a safe place and repair the flat tire temporarily with the

emergency tire puncture repair kit. (P. 601)

The vehicle becomes stuck

● Try the procedure for when the vehicle becomes stuck in mud, dirt, or

snow. (P. 635)

Content      ..     9      10      11
