680
9-2. Customization
■ Changing on the navigation or multimedia system screen
(vehicles with a navigation or multimedia system)
1
Press
2
Select “Vehicle” on the “Setup” screen.
Select the desired item.
Various settings can be changed. Refer to the list of settings that
can be changed for details.
Customizable features
Some function settings are changed simultaneously with other func-
tions when customized. Contact any authorized Toyota retailer or
Toyota authorized repairer, or any reliable repairer for further details.
Settings that can be changed using the multi-information display
1
Settings that can be changed using the navigation or multimedia
2
system screen (vehicles with a navigation or multimedia system)
Settings that can be changed by any authorized Toyota retailer or
3
Toyota authorized repairer, or any reliable repairer
Definition of symbols: O = Available, — = Not available
C-HR_HV_OM_Europe_OM10538E
9-2. Customization
681
■ Gauges, meters and multi-information display (P. 129)
Customized
Function
Default setting
1
2
3
setting
Language*1
English
O
O
O
*2
km (km/L)
Units*1
km (L/100 km)
O
O
O
miles (MPG)
On
Eco Driving Indicator Light
Off
O
-
O
(Self-lighting)
Current fuel
consumption
(gauge dis-
play)
Drive information 1
O
-
O
*3
Average fuel
economy
(after reset)
Distance
(driving range)
Drive information 2
O
-
O
Average vehi-
*3
cle speed
(after reset)
Pop-up display
On
Off
O
-
O
*
1: The default setting varies according to country.
*2: German, French, Spanish, Italian, Portuguese, Dutch, Swedish, Norwe-
gian, Danish, Russian, Finnish, Greek, Polish, Ukrainian, Turkish, Hungar-
ian, Czech, Slovak, Romanian
*3: 2 of the following items: current fuel consumption (gauge display), current
fuel consumption (numerical display), average fuel economy (after reset),
9
average fuel economy (after start), average fuel economy (after refuel),
average vehicle speed (after reset), average vehicle speed (after start),
elapsed time (after reset), elapsed time (after start), distance
(driving
range), distance (after start), blank.
C-HR_HV_OM_Europe_OM10538E
682
9-2. Customization
■ Instrument cluster (P. 132)
Customized
Function
Default setting
1
2
3
setting
Sensor sensitivity for
darkening the brightness
of the instrument cluster
Standard
-2 to 2
-
-
O
depending on the outside
brightness
Sensor sensitivity for
returning the brightness of
the instrument cluster to
Standard
-2 to 2
-
-
O
the original level depend-
ing on the outside bright-
ness
■ Smart entry & start system and wireless remote control
(P. 150, 163)
Customized
Function
Default setting
1
2
3
setting
Operation signal
(emer-
On
Off
-
O
O
gency flashers)
Time elapsed before the
60 seconds
automatic door lock func-
tion is activated if a door is
30 seconds
-
-
O
not opened after being
120 seconds
unlocked
Open door reminder
buzzer (When locking the
On
Off
-
-
O
vehicle)
C-HR_HV_OM_Europe_OM10538E
9-2. Customization
683
■ Smart entry & start system (P. 163)
Customized
Function
Default setting
1
2
3
setting
Smart entry & start sys-
On
Off
-
O
O
tem
Smart door unlocking
All the doors
Driver’s door
-
O
O
Number of consecutive
As many as
2 times
-
-
O
door lock operations*
desired
*: Vehicles without an alarm
■ Wireless remote control (P. 150)
Customized
Function
Default setting
1
2
3
setting
Wireless remote control
On
Off
-
-
O
Driver’s door
unlocked in
All doors
one step, all
Unlocking operation
unlocked in
-
O
O
doors
one step
unlocked in
two step
■ Outside rear view mirrors (P. 190)
Customized
Function
Default setting
1
2
3
setting
Off
Linked to the
Automatic mirror folding
locking/
Linked to
-
-
O
and extending operation
unlocking of
operation of
the doors
the power
switch
9
C-HR_HV_OM_Europe_OM10538E
684
9-2. Customization
■ Power windows (P. 193)
Customized
Function
Default setting
1
2
3
setting
Mechanical key linked
Off
On
-
-
O
operation (open)
Mechanical key linked
Off
On
-
-
O
operation (close)
Wireless remote control
Off
On
-
-
O
linked operation (open)
Wireless remote control
Off
On
-
-
O
linked operation (close)
Mechanical key, wireless
remote control linked
On
Off
-
-
O
operation signal (buzzer)
■ Turn signal lever (P. 235)
Customized
Function
Default setting
1
2
3
setting
Off
Times of flashing of the
lane change signal flash-
3
5
-
-
O
ers
7
■ Automatic light control system (P. 244)
Customized
Function
Default setting
1
2
3
setting
Light sensor sensitivity
Level 0
Level -2 to 2
-
O
O
60 seconds
Time elapsed before
headlights turn off (follow
30 seconds
90 seconds
-
-
O
me home system)
120 seconds
C-HR_HV_OM_Europe_OM10538E
9-2. Customization
685
■ Toyota parking assist-sensor* (P. 351)
Customized
Function
Default setting
1
2
3
setting
Detection distance of the
Far
Near
-
-
O
side sensors
Buzzer volume
3
1 to 5
-
-
O
*: If equipped
■ Follow me home system (P. 245)
Customized
Function
Default setting
1
2
3
setting
60 seconds
Time elapsed before
headlights automatically
30 seconds
90 seconds
-
-
O
turn off
120 seconds
■ PCS (Pre-Collision System)* (P. 274)
Customized
Function
Default setting
1
2
3
setting
Pre-collision system
On
Off
O
-
O
Far
Warning timing
Middle
O
-
O
Near
*: If equipped
9
C-HR_HV_OM_Europe_OM10538E
686
9-2. Customization
■ LDA (Lane Departure Alert with steering control)* (P. 289)
Customized
Function
Default setting
1
2
3
setting
Steering assist
On
Off
O
-
O
Alert sensitivity
Standard
High
O
-
O
Vehicle sway warning
On
Off
O
-
O
Low
Vehicle sway
Standard
O
-
O
warning sensitivity
High
*: If equipped
■ RSA (Road Sign Assist)* (P. 301)
Default
Customized
Function
1
2
3
setting
setting
No notification
Excess
Only visual
O
-
O
speed
Visual and
audible
Notification
method
No notification
Others
Only visual
O
-
O
Visual and
audible
5 km/h
(3 mph)
Excess speed notification
2 km/h
O
-
O
level
(1 mph)
10 km/h
(5 mph)
*: If equipped
■ Air conditioning system (P. 478)
Customized
Function
Default setting
1
2
3
setting
Switching between out-
side air and recirculated
On
Off
-
O
O
air mode linked to A/C
auto switch operation
C-HR_HV_OM_Europe_OM10538E
9-2. Customization
687
■ Illumination (P. 490)
Customized
Function
Default setting
1
2
3
setting
Off
Time elapsed before the
15 seconds
7.5 seconds
-
O
O
interior lights turn off
30 seconds
Operation after the power
On
Off
-
-
O
switch is turned off
Operation when the doors
On
Off
-
-
O
are unlocked
Operation when you
approach the vehicle with
On
Off
-
-
O
the electronic key on your
person
Mirror illumination*
On
Off
-
-
O
Off
Time elapsed before the
mirror illumination turn
15 seconds
7.5 seconds
-
O
O
off*
30 seconds
Operation of the mirror
illumination when you
approach the vehicle with
On
Off
-
-
O
the electronic key on your
person*
Operation of the mirror
illumination when the
On
Off
-
-
O
doors are unlocked*
Interior lights illumination
On
Off
-
-
O
9
control
*: If equipped
C-HR_HV_OM_Europe_OM10538E
688
9-2. Customization
■ In the following situations, customize mode in which the settings can be
changed through the multi-information display will automatically be
turned off
● A warning message appears after the customize mode screen is displayed.
● The power switch is turned off.
●The vehicle begins to move while the customize mode screen is displayed.
WARNING
■ Cautions during customization
As the hybrid system needs to be operating during customization, ensure
that the vehicle is parked in a place with adequate ventilation. In a closed
area such as a garage, exhaust gases including harmful carbon monoxide
(CO) may collect and enter the vehicle. This may lead to death or a serious
health hazard.
NOTICE
■ During customization
To prevent 12-volt battery discharge, ensure that the hybrid system is oper-
ating while customizing features.
C-HR_HV_OM_Europe_OM10538E
9-3. Initialization
689
Items to initialize
The following items must be initialized for normal system opera-
tion after such cases as the 12-volt battery being reconnected,
or maintenance being performed on the vehicle:
Item
When to initialize
Reference
Power window
• When functioning abnormally
P. 195
S-IPA
(Simple Intelligent
• After reconnecting or chang-
Parking Assist System)
(if
P. 393
ing the 12-volt battery
equipped)
• When changing the tire size
• When changing the tire infla-
Tire pressure warning sys-
tion pressure by changing
P. 543
tem
traveling speed or load
weight, etc.
9
C-HR_HV_OM_Europe_OM10538E
690
9-3. Initialization
C-HR_HV_OM_Europe_OM10538E
691
Index
What to do if...
(Troubleshooting)
692
Alphabetical index
696
For vehicles with navigation system or multimedia system,
refer to the
“Navigation and multimedia system Owner’s
manual” for information regarding the equipment listed below.
• Navigation system
• Hands-free system (for cellular phone)
• Audio system
• Rear view monitor system
C-HR_HV_OM_Europe_OM10538E
692
What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
If you have a problem, check the following before contacting any
authorized Toyota retailer or Toyota authorized repairer, or any
reliable repairer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
● If you lose your mechanical keys, new genuine mechanical keys can be
made by any authorized Toyota retailer or Toyota authorized repairer, or
any reliable repairer. (P. 145)
● If you lose your electronic keys, the risk of vehicle theft increases signifi-
cantly. Contact any authorized Toyota retailer or Toyota authorized
repairer, or any reliable repairer immediately. (P. 148)
The doors cannot be locked or unlocked
● Is the electronic key battery weak or depleted? (P. 561)
● Is the power switch in ON mode?
When locking the doors, turn the power switch off. (P. 222)
● Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
● The function may not operate properly due to the condition of the radio
wave. (P. 166)
The rear door cannot be opened
● Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (P. 153)
C-HR_HV_OM_Europe_OM10538E
What to do if... (Troubleshooting)
693
If you think something is wrong
The hybrid system does not start
● Did you press the power switch while firmly depressing the brake pedal?
(P. 221)
● Is the shift lever in P? (P. 224)
● Is the electronic key anywhere detectable inside the vehicle? (P. 164)
● Is the electronic key battery weak or depleted?
In this case, the hybrid system can be started in a temporary way.
(P. 649)
● Is the 12-volt battery discharged? (P. 651)
The shift lever cannot be shifted from P even if you depress
the brake pedal
● Is the power switch in ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
power switch in ON mode. (P. 233)
The windows do not open or close by operating the power
window switches
● Is the window lock switch pressed?
The power windows except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. (P. 193)
The power switch is turned off automatically
● The auto power off function will be operated if the vehicle is left in
ACCESSORY or ON mode (the hybrid system is not operating) for a
period of time. (P. 223)
C-HR_HV_OM_Europe_OM10538E
694
What to do if... (Troubleshooting)
A warning buzzer sounds during driving
● The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? (P. 599)
● The parking brake indicator is on
Is the parking brake released? (P. 236)
Depending on the situation, other types of warning buzzer may also sound.
(P. 595, 606)
An alarm is activated and the horn sounds
(vehicles with alarm)
● Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. (P. 106)
To stop the alarm, turn the power switch to ON mode or start the hybrid sys-
tem.
A warning buzzer sounds when leaving the vehicle
● Is the electronic key left inside the vehicle?
Check the message on the multi-information display. (P. 606)
A warning light turns on or a warning message is displayed
● When a warning light turns on or a warning message is displayed, refer to
P. 595, 606.
C-HR_HV_OM_Europe_OM10538E
What to do if... (Troubleshooting)
695
When a problem has occurred
If you have a flat tire
● Vehicles with an emergency tire puncture repair kit:
Stop the vehicle in a safe place and repair the flat tire temporarily with the
emergency tire puncture repair kit. (P. 612)
● Vehicles with spare tire:
Stop the vehicle in a safe place and replace the flat tire with the spare tire.
(P. 632)
The vehicle becomes stuck
● Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. (P. 662)
C-HR_HV_OM_Europe_OM10538E
696
Alphabetical index
Alphabetical index
A
Airbags
43
A/C
478
Airbag manual on-off
Air conditioning filter
558
system
57
Climate preference
481
Airbag operating conditions
51
ABS
Airbag precautions for your
(Anti-lock Brake System)
402
child
46
Function
402
Airbag warning light
596
Warning light
596
Correct driving posture
36
Air conditioning filter
558
Curtain shield airbag
Air conditioning system
478
operating conditions
51
Air conditioning filter
558
Curtain shield airbag
Climate preference
481
precautions
48
Air intake vent
93
General airbag precautions
46
Airbag manual on-off
Locations of airbags
43
system
57
Modification and disposal of
airbags
50
Side airbag operating
conditions
51
Side airbag precautions
47
Side and curtain shield
airbags operating
conditions
51
Side and curtain shield
airbags precautions
48
SRS airbags
43
Alarm
106
Anchor brackets
84
Antenna
Smart entry & start system ...163
C-HR_HV_OM_Europe_OM10538E
