Toyota C-HR Hybrid (2017 year). Manual - part 19

306

4-5. Using the driving support systems

■ When driving vehicle in country with different speed unit

Since RSA recognizes signs based on the set unit of the meter, it is neces-

sary to change the set unit of the meter. Adjust the set unit of the meter to the

speed unit of signs in the current location. (P. 679)

■ Turning the system on/off

1

Press

“” or

“” of meter control

switches and select

2

Press

“” or

“” of meter control

switches and select

, and press

■ Speed limit sign display

If the power switch was last turned off while a speed limit sign was displayed

on the multi-information display, the same sign displays again when the

power switch is turned ON mode.

■ Customization

Setting (e.g. speeding warning threshold) can be changed.

(Customizable feature: P. 679)

C-HR_HV_OM_Europe_OM10538E

4-5. Using the driving support systems

307

Dynamic radar cruise controlwith full-speed

range

Summary of functions

In vehicle-to-vehicle distance control mode, the vehicle automatically

accelerates, decelerates and stops to match the speed changes of the

preceding vehicle even if the accelerator pedal is not depressed. In

constant speed control mode, the vehicle runs at a fixed speed.

Use the dynamic radar cruise control with full-speed range on free-

ways and highways.

● Vehicle-to-vehicle distance control mode (P. 310)

● Constant speed control mode (P. 317)

1

Display

4

2

Indicators

3

Set speed

4

Vehicle-to-vehicle

distance

switch

Cruise control switch

5

: If equipped

C-HR_HV_OM_Europe_OM10538E

308

4-5. Using the driving support systems

WARNING

■ Before using dynamic radar cruise control with full-speed range

Driving safely is the sole responsibility of the driver. Do not rely solely on the

system, and drive safely by always paying careful attention to your sur-

roundings.

The dynamic radar cruise control with full-speed range provides driving

assistance to reduce the driver’s burden. However, there are limitations to

the assistance provided.

Even when the system is functioning normally, the condition of the preced-

ing vehicle as detected by the system may differ from the condition

observed by the driver. Therefore, the driver must always remain alert,

assess the danger of each situation and drive safely. Relying on this system

or assuming the system ensures safety while driving can lead to an acci-

dent, resulting in death or serious injury.

■ Cautions regarding the driving assist systems

Observe the following precautions, as there are limitations to the assistance

provided by the system.

Failure to do so may cause an accident resulting in death or serious injury.

●Assisting the driver to measure following distance

The dynamic radar cruise control with full-speed range is only intended to

help the driver in determining the following distance between the driver’s

own vehicle and a designated vehicle traveling ahead. It is not a mecha-

nism that allows careless or inattentive driving, and it is not a system that

can assist the driver in low-visibility conditions. It is still necessary for

driver to pay close attention to the vehicle’s surroundings.

●Assisting the driver to judge proper following distance

The dynamic radar cruise control with full-speed range determines

whether the following distance between the driver’s own vehicle and a

designated vehicle traveling ahead is within a set range. It is not capable

of making any other type of judgement. Therefore, it is absolutely neces-

sary for the driver to remain vigilant and to determine whether or not there

is a possibility of danger in any given situation.

●Assisting the driver to operate the vehicle

The dynamic radar cruise control with full-speed range has limited capabil-

ity to prevent or avoid a collision with a vehicle traveling ahead. Therefore,

if there is ever any danger, the driver must take immediate and direct con-

trol of the vehicle and act appropriately in order to ensure the safety of all

involved.

C-HR_HV_OM_Europe_OM10538E

4-5. Using the driving support systems

309

WARNING

■ To avoid inadvertent dynamic radar cruise control with full-speed

range activation

Switch the dynamic radar cruise control with full-speed range off using the

“ON-OFF” button when not in use.

■ Situations unsuitable for dynamic radar cruise control with full-speed

range

Do not use dynamic radar cruise control with full-speed range in any of the

following situations.

Doing so may result in inappropriate speed control and could cause an acci-

dent resulting in death or serious injury.

●Roads where there are pedestrians, cyclists, etc.

●In heavy traffic

●On roads with sharp bends

●On winding roads

4

●On slippery roads, such as those covered with rain, ice or snow

●On steep downhills, or where there are sudden changes between sharp up

and down gradients

Vehicle speed may exceed the set speed when driving down a steep hill.

● At entrances to freeways and highways

● When weather conditions are bad enough that they may prevent the sen-

sors from detecting correctly (fog, snow, sandstorm, heavy rain, etc.)

● When there is rain, snow, etc., on the front surface of the radar sensor or

camera sensor

● In traffic conditions that require frequent repeated acceleration and decel-

eration

● When your vehicle is towing a trailer or during emergency towing

● When an approach warning buzzer is heard often

C-HR_HV_OM_Europe_OM10538E

310

4-5. Using the driving support systems

Driving in vehicle-to-vehicle distance control mode

This mode employs a radar sensor to detect the presence of vehicles

up to approximately 100 m (328 ft.) ahead, determines the current

vehicle-to-vehicle following distance, and operates to maintain a suit-

able following distance from the vehicle ahead.

Note that vehicle-to-vehicle distance will close in when traveling on long

downhill slopes.

Example of constant speed cruising

1

When there are no vehicles ahead

The vehicle travels at the speed set by the driver. The desired vehi-

cle-to-vehicle distance can also be set by operating the vehicle-to-vehicle

distance switch.

C-HR_HV_OM_Europe_OM10538E

312

4-5. Using the driving support systems

Setting the vehicle speed (vehicle-to-vehicle distance control

mode)

Press the “ON-OFF” button to

1

activate the cruise control.

Radar cruise control indicator will

come on and a message will be

displayed on the multi-information

display.

Press the button again to deacti-

vate the cruise control.

If the “ON-OFF” button is pressed

and held for 1.5 seconds or more,

the system turns on in constant

speed control mode. (P. 317)

Accelerate or decelerate, with

2

accelerator pedal operation, to

the desired vehicle speed

(above approximately 50 km/h

[30 mph]) and push the lever

down to set the speed.

Cruise control “SET” indicator will

come on.

The vehicle speed at the moment

the lever is released becomes the

set speed.

If the lever is operated while the

vehicle speed is below approxi-

mately 50 km/h (30 mph) and a

preceding vehicle is present, the

set speed will be adjusted to

approximately 50 km/h (30 mph).

C-HR_HV_OM_Europe_OM10538E

4-5. Using the driving support systems

313

Adjusting the set speed

To change the set speed, operate the lever until the desired set speed

is displayed.

Increases the speed

1

(Except when the vehicle has been

stopped by system control in vehi-

cle-to-vehicle distance control

mode)

Decreases the speed

2

Fine adjustment: Momentarily

move the lever in the desired

direction.

Large adjustment: Hold the lever up or down to change the speed,

and release when the desired speed is reached.

4

In the vehicle-to-vehicle distance control mode, the set speed will be

increased or decreased as follows:

Fine adjustment: By 5 km/h (3.1 mph)*1 or 5 mph (8 km/h)*2 each time the

lever is operated

Large adjustment: Increases or decreases in 5 km/h (3.1 mph)*1 or 5 mph

(8 km/h)*2 increments for as long as the lever is held

In the constant speed control mode (P. 317), the set speed will be

increased or decreased as follows:

Fine adjustment: By 1 km/h (0.6 mph)*1 or 1 mph (1.6 km/h)*2 each time

the lever is operated

Large adjustment: The speed will continue to change while the lever is

held.

*1: When the set speed is shown in “km/h”

*2: When the set speed is shown in “MPH”

C-HR_HV_OM_Europe_OM10538E

314

4-5. Using the driving support systems

Changing the vehicle-to-vehicle distance (vehicle-to-vehicle dis-

tance control mode)

Pressing the button changes the

Preceding vehicle mark

vehicle-to-vehicle distance as fol-

lows:

1

Long

2

Medium

3

Short

The vehicle-to-vehicle distance is

set automatically to long mode

when the power switch is turned

ON mode.

If a vehicle is running ahead of you, the preceding vehicle mark will also be

displayed.

Vehicle-to-vehicle distance settings (vehicle-to-vehicle distance

control mode)

Select a distance from the table below. Note that the distances shown

correspond to a vehicle speed of 80 km/h (50 mph). Vehicle-to-vehicle

distance increases/decreases in accordance with vehicle speed.

When the vehicle is stopped by system control, the vehicle-to-vehicle

distance will be about 3 m (10 ft.) to 5 m (16 ft.) regardless of the vehi-

cle-to-vehicle distance setting.

Distance options

Vehicle-to-vehicle distance

Long

Approximately 50 m (160 ft.)

Medium

Approximately 40 m (130 ft.)

Short

Approximately 30 m (100 ft.)

C-HR_HV_OM_Europe_OM10538E

4-5. Using the driving support systems

315

Resuming follow-up cruising when the vehicle has been stopped

by system control (vehicle-to-vehicle distance control mode)

After the vehicle ahead of you

starts off, push the lever up.

Your vehicle will also resume fol-

low-up cruising if the accelerator

pedal is depressed after the vehi-

cle ahead of you starts off.

Canceling and resuming the speed control

Pulling the lever toward you

1

cancels the speed control.

4

The speed control is also canceled

when the brake pedal is

depressed.

(When the vehicle has been

stopped by system control,

depressing the brake pedal does

not cancel the setting.)

2

Pushing the lever up resumes the cruise control and returns vehicle

speed to the set speed.

However, when a vehicle ahead is not detected, cruise control does not

resume when the vehicle speed is approximately 40 km/h (25 mph) or less.

C-HR_HV_OM_Europe_OM10538E

316

4-5. Using the driving support systems

Approach warning (vehicle-to-vehicle distance control mode)

When your vehicle is too close to

a vehicle ahead, and sufficient

automatic deceleration via the

cruise control is not possible, the

display will flash and the buzzer

will sound to alert the driver. An

example of this would be if

another driver cuts in front of you

while you are following a vehicle.

Depress the brake pedal to

ensure an appropriate vehicle-to-

vehicle distance.

■ Warnings may not occur when

In the following instances, warnings may not occur even when the

vehicle-to-vehicle distance is small.

● When the speed of the preceding vehicle matches or exceeds

your vehicle speed

● When the preceding vehicle is traveling at an extremely slow

speed

● Immediately after the cruise control speed was set

● When depressing the accelerator pedal

C-HR_HV_OM_Europe_OM10538E

4-5. Using the driving support systems

317

Selecting constant speed control mode

When constant speed control mode is selected, your vehicle will main-

tain a set speed without controlling the vehicle-to-vehicle distance.

Select this mode only when vehicle-to-vehicle distance control mode

does not function correctly due to a dirty radar sensor.

With the cruise control off,

1

press and hold the “ON-OFF”

button for 1.5 seconds or more.

Immediately after the

“ON-OFF”

button is pressed, the radar cruise

control indicator will come on.

Afterwards, it switches to the cruise

control indicator.

Switching to constant speed con-

trol mode is only possible when

4

operating the lever with the cruise

control off.

Accelerate or decelerate, with

2

accelerator pedal operation, to

the desired vehicle speed

(above approximately 50 km/h

[30 mph]) and push the lever

down to set the speed.

Cruise control “SET” indicator will

come on.

The vehicle speed at the moment

the lever is released becomes the

set speed.

Adjusting the speed setting: P. 313

Canceling and resuming the speed setting: P. 315

C-HR_HV_OM_Europe_OM10538E

320

4-5. Using the driving support systems

● Vehicles with small rear ends (trailers with no load on board, etc.)

● Motorcycles traveling in the same lane

● When water or snow thrown up by the surrounding vehicles hinders the

detecting of the sensor

● When your vehicle is pointing upwards

(caused by a heavy load in the luggage

compartment, etc.)

● Preceding vehicle has an extremely high

ground clearance

C-HR_HV_OM_Europe_OM10538E

4-5. Using the driving support systems

321

■ Conditions under which the vehicle-to-vehicle distance control mode

may not function correctly

In the case of the following conditions, operate the brake pedal (or accelera-

tor pedal, depending on the situation) as necessary.

As the sensor may not be able to correctly detect vehicles ahead, the system

may not operate properly.

● When the road curves or when the lanes

are narrow

● When steering wheel operation or your

position in the lane is unstable

4

● When the vehicle ahead of you decelerates suddenly

C-HR_HV_OM_Europe_OM10538E

322

4-5. Using the driving support systems

Cruise control

Summary of functions

Use the cruise control to maintain a set speed without depressing the

accelerator pedal.

1

Indicators

2

Set speed

3

Cruise control switch

: If equipped

C-HR_HV_OM_Europe_OM10538E

Content   ..  17  18  19  20   ..
