SERVICE AND APPEARANCE CARE
Secondary Latch System
To release the spare tire from the second-
Your vehicle has an underbody mounted
ary latch, do the following:
tire hoist assembly equipped with a sec-
1)
If the cable is not visible, start this pro-
ondary latch system. It is designed to stop
cedure at Step 3.
the compact spare tire from suddenly fall-
ing off your vehicle if the cable holding the
spare tire is damaged. For the secondary
latch to work, the tire must be stowed with
the valve stem pointing down. Refer to
“Storing a Flat or Spare Tire and Tools” in
this section for instructions on storing the
spare tire correctly.
WARNING
806546
Before beginning this procedure read
5)
Turn the wheel wrench clockwise to
all the instructions. Failure to read
and follow the instructions could
raise the jack until it lifts the secondary
latch spring.
damage the hoist assembly and you
and others could get hurt. Read and
806961
6)
Keep raising the jack until the spare tire
stops moving upward and is held firmly
follow the instructions listed next.
2)
If the cable is visible, place the wrench
in place, this lets you know that the sec-
on the hoist drive nut and turn the
ondary latch has released.
wrench counterclockwise until approxi-
WARNING
7)
Lower the jack by turning the wheel
mately 6 inches (15 cm) of cable is
wrench counterclockwise. Keep lower-
Someone standing too close during
exposed.
ing the jack until the spare tire is resting
the procedure could be injured by the
3)
Attach the wheel wrench to the jack and
on the wheel wrench.
jack. If the spare tire does not slide
raise the jack at least 10 turns.
off the jack completely, make sure no
4)
Place the jack under the vehicle, ahead
one is behind you or on either side of
of the rear bumper. Position the center
you as you pull the jack out from the
lift point of the jack under the center of
under spare.
the spare tire.
5-43

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICE AND APPEARANCE CARE
Storing a Compact Spare Tire
WARNING
Storing a jack, a tire, or other equip-
ment in the passenger compartment
of the vehicle could cause injury. In a
sudden stop or collision, loose
equipment could strike someone.
Store all these in the proper place.
WARNING
The underbody-mounted spare tire
806548
1613524
needs to be stored with the valve
stem pointing down. If the spare tire
8) Grasp the spare tire with both hands
10)Tilt the retainer and slip it through the
is stored with the valve stem pointing
and pull it out from under the vehicle.
wheel opening when the spare tire has
upward, its secondary latch will not
9) Reach under the vehicle and remove
been completely lowered.
work properly and the spare tire
the wheel wrench and jack.
11)Turn the wrench clockwise to raise the
could loosen and suddenly fall from
cable back up if the cable is hanging.
your vehicle. If this happened when
Have the hoist assembly inspected as
your vehicle was being driven, the
soon as you can. You will not be able to
tire might contact a person or
store a spare tire using the hoist assembly
another vehicle, causing injury and,
until it has been repaired or replaced.
of course, damage to itself as well.
Be sure the underbody-mounted
spare tire is stored with its valve
stem pointing down.
5-44

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICE AND APPEARANCE CARE
Follow this diagram to store
the under-
1)
Put the tire (D) on the ground at the
body-mounted spare tire.
rear of the vehicle.
2)
Ensure the valve stem is pointed down
and to the rear. Then pull the retainer
(C) through the wheel.
3)
Pull the secondary retainer (C) through
the wheel. The secondary retainer is
located under the secondary latch
spring and is smaller than the spare tire
retainer to allow it to fit through the road
wheel center cap hole.
4)
Place the wheel wrench (A) onto the
hoist drive nut.
5)
Raise the tire fully against the under-
side of the vehicle by turning the wheel
811589
wrench clockwise. Continue turning it
6)
Make sure the tire is stored securely.
1218662
clockwise until you hear two clicks or
Push, pull (A), and then try to turn (B)
feel it skip twice. This indicates that the
A. Wheel Wrench
the tire. If the tire moves, use the wheel
tire is secure and the cable is tight. The
B. Hoist Shaft
wrench and socket end of the extension
spare tire hoist cannot be overtight-
C. Secondary Retainer
to tighten the cable.
ened.
D. Spare Tire
7)
Return the equipment to the proper
(Valve Stem Pointed Down)
location in the vehicle as shown next.
5-45

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICE AND APPEARANCE CARE
To store the tools, do the following:
Storing a Full-Sized Flat Tire
To store a full-sized flat tire do the follow-
1)
Place the wheel wrench into the bag.
ing:
2)
Use the hook and loop fastener straps
1)
Remove the tire storage bag and cable
to secure the bag to the fully collapsed
package from the jack storage area.
jack.
2)
If your vehicle has aluminum wheels,
remove the center cap by tapping the
back of the cap with the wheel wrench.
3)
If your vehicle has Third Row Seating,
fold down the seat backs. Refer to
“Third Row Seat” in “Rear Seats” in the
“Seats and Restraint Systems” section.
4)
Put the flat tire in the tire storage bag
and place it the rear storage area. If
your vehicle has Third Row Seating,
1829965
place the tire with the valve stem point-
5)
Pull the cable
(A) through the door
ing toward the front of the vehicle. If
striker (C) and the center of the wheel.
your vehicle does not have Third Row
Seating, place the tire with the valve
stem pointing toward the rear of the
1399885
vehicle.
3)
Install the jack in the right side panel of
cargo area and secure with the wing
bolt.
4)
Reinstall the access door.
812750
6) Hook the cable (A) onto the outside of
the liftgate hinges (B).
5-46

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICE AND APPEARANCE CARE
7)
Pull on the cable to make sure it is
ble and make sure the spare tire is cor-
secure.
rectly inflated. The compact spare is made
CAUTION
to perform well at speeds up to 65 mph
Tire chains will not fit your compact
(105 km/h) for distances up to 3000 miles
spare. Using them can damage your
(5000 km), so you can finish your trip and
vehicle and can damage the chains
have the full-size tire repaired or replaced
too. Do not use tire chains on your
where you want. You must calibrate the
compact spare.
tire inflation monitor system, if your vehicle
has this feature, after installing or remov-
ing the compact spare. Refer to “Tire Pres-
sure Monitor System” in this section. The
system may not work correctly when the
compact spare is installed on the vehicle.
Of course, it’s best to replace the spare
with a full-size tire as soon as you can. The
spare will last longer and be in good shape
1829968
in case you need it again.
8)
Make sure the metal tube is center at
CAUTION
the striker. Push the tube towards the
front of the vehicle.
When the compact spare is installed,
9)
Close the liftgate.
do not take your vehicle through an
10)If your vehicle has Third Row Seating,
automatic car wash with guide rails.
return the third row seat to their upright
The compact spare can get caught on
position. Refer to “Third Row Seat” in
the rails. That can damage the tire
“Rear Seats” in the
“Seats and
and wheel, and maybe other parts of
Restraint Systems” section.
your vehicle.
Compact Spare Tire
Do not use the compact spare on other
Although the compact spare tire was fully
vehicles. And do not mix the compact
inflated when the vehicle was new, it can
spare tire or wheel with other wheels or
lose air after a time. Check the inflation
tires. They will not fit. Keep the spare tire
pressure regularly. It should be 60 psi (420
and its wheel together.
kPa).
After installing the compact spare on the
vehicle, you should stop as soon as possi-
