SsangYong Rexton. Service manual - part 658

BODY EXTERIOR 9C-5

SSANGYONG Y200

1 Glass Lifter
2 Ball Stud Bracket
3 Bolt Pad
4 Spoiler
5 Glass Open Hinge
6 Glass Handle
7 Glass Weather Strip
8 Glass Release Handle

9 Over Slam Bumper

10 Latch
11 Striker
12 Panel
13 Glass (Standard : 4.0 T  Flip-Up : 5.0 T)
14 Bracket Cover Of Ball Stud
15 Bolt

SSANGYONG Y200

9C-6 BODY EXTERIOR

1 Bolt
2 Shock Absorber
3 Hood Hinge

4 Hood
5 Hood Striker

YAD9C040

HOOD

BODY EXTERIOR 9C-7

SSANGYONG Y200

SUN-ROOF AND ROOF RACK

1 Sun-Roof Glass
2 Glass Moulding
3 Head-Lining Assembly
4 Roof Channel

5 Sun-Roof Glass Panel
6 Roof Carrier
7 Nut
8 Motor And Relay Box

YAD9C050

SSANGYONG Y200

9C-8 BODY EXTERIOR

MOULDING

1 Nut (M5)
2 Wheel Arch Front Moulding
3 Front Door Garnish
4 Rear Door Garnish

5 Wheel Arch Rear Moulding
6 Moulding
7 Side Step

YAD9C060
