SsangYong Rexton. Service manual - part 488
REAR AXLE 3D-5
SSANGYONG Y200
CROSS SECTIONAL VIEW
YAD3D020
1 Rear Axle Shaft Assembly2 Bracket Assembly3 Hub Oil Seal4 Bolt5 Axle Shaft Tube
6 Coil Spring Seat (Lower)7 Caliper Assembly8 Input Shaft/Flange9 Rod Mounting Bracket
10 Wheel Speed Sensor
