SSANGYONG Y200 1B3-80 DIESEL ENGINE MECHANICAL YAD1BFB0 YAD1BFC0 YAD1BF90 YAD1BC20 Installation Procedure 1. Put the same alignment mark on the new crankshaft sprocket as in the old sprocket. Notice: Check the timing chain, camshaft 2. Install the new crankshaft sprocket (12) by using a drift 116 589 07 15 00 (21). Notice: Align the groove of sprocket and woodruff 3. Fit the timing chain (4) on the crankshaft sprocket (12). Notice: Align the alignment marks (arrow) on the 4. Install the camshaft sprocket (3). Installation Notice Tightening Torque 25 N•m (18 lb-ft)+ 90° Pay attention on the alignment marks and dowel |
