ELECTRICAL WIRING DIAGRAMS 5-185
SSANGYONG REXTON XDi (LHD)
A. CONNECTOR INFORMATION
B. CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION
Connector Number
(Pin Number, Color)
Engine Room Fuse Box (J) - Engine
Engine Room Fuse Box (K) - Engine
Main - Roof
Main - Floor (LH)
Main - Floor (LH)
Main - Floor (LH)
Main - Floor (RH)
Floor - T/M
Floor - T/M
Floor - Parking Aid
W/H Floor
W/H Floor
C107 (14Pin, White)
C108 (4Pin, Colorless)
C202 (15Pin, White)
C205 (11Pin, White)
C208 (20Pin, Black)
C209 (22Pin, Yellow)
C216 (18Pin, White)
C901 (16Pin, White)
C901 (2Pin, White)
C904 (8Pin, White)
G304
G305
Connecting Wiring
Harness
Engine Room Fuse Box
Engine Room Fuse Box
Under the I/P Fuse Box
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Inside Co-Driver Side Cowl PNL
Left the T/C (Under the Floor)
Left the T/C (Under the Floor)
Inside the Left RR Bumper
Behind the Quarter Grass #1
Behind the Quarter Grass #1
A/T
M/T
Parking Aid
Remark
Connector Position
