SsangYong Rexton. Service manual - part 280
ELECTRICAL WIRING DIAGRAMS 5-153
SSANGYONG REXTON XDi (LHD)
A. CONNECTOR INFORMATION
B. CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION
Connector Number
(Pin Number, Color)
Engine Room Fuse Box (B) - Engine
Engine Room Fuse Box (D) - Engine
Engine Room Fuse Box (F) - Engine
Engine Room Fuse Box (M) - Engine
Main - Floor (LH)
Engine - Main (RH)
W/H Main
W/H Main
W/H Engine
W/H Engine
W/H Engine
W/H Main
C102 (20Pin, White)
C104 (20Pin, White)
C106 (18Pin, White)
C109 (14Pin, White)
C203 (13Pin, Green)
C210 (13Pin, Green)
S204 (14Pin, Black)
S207 (14Pin, Black)
G101
G102
G105
G201
Connecting Wiring
Harness
Engine Room Fuse Box
Engine Room Fuse Box
Engine Room Fuse Box
Engine Room Fuse Box
Under the I/P Fuse Box
Inside Driver Side Cowl PNL
Behind the Left the FATC
Behind the Right the FATC
Center the Engine Room Fuse Box
Center BATT
Behine the Right Head Lamp
Inside Driver Side Cowl PNL
GND
Tail Lamp
Remark
Connector Position
