DI05-10
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
LUBRICATION SYSTEM
DI ENG SM - 2004.4
Y220_05010
ENGINE OIL CHANGE
Change interval: Initial change: 5,000 km, Change every 10,000 km or 12 months
Engine Oil Changing Procedures
1. Park the vehicle on the level ground and warm up the
engine until it reaches normal operating temperature.
2. Stop the engine and wait around 5 minutes. Remove the
oil filler cap, oil filter and oil drain plug to drain the oil.
3. Install new oil filter and tighten the drain plug with specified
tighten torque.
5. Close the oil filler cap and start the engine.
6. Stop the engine again and check the oil level. Add the engine oil if needed and check for the oil leaks.
Oil drain plug
25 ± 2.5 Nm
4. Fill the engine oil through the oil filler opening.
Frequently check and add if needed. Shorten the change interval under severe conditions.
* Severe condition:
- When most trips include extended idling and/or frequent low-speed operation as in stop-and-go traffic.
- When most trips are less than 6 km (Operating when outside temperatures remain below freezing and
when most trips are less than 16 km)
- When operating in dusty, sandy and salty areas
- In hilly or moutainous terrain
- When doing frequent trailer towing
Notice
Water separation from the fuel filter should be performed when changing the engine oil.
Notice
After driving, the engine oil temperature may be high
enough to burn you. Wait until the oil is cooled down.
Notice
• Over-tightening may cause oil leaks.
• Replace the drain plug washer with new one.
Notice
The oil should not go above the upper mark on the dipstick. This would lead, for example, to increased oil
consumption, fouling of the spark plugs and excessive formation of carbon residue.
