Renault Megane Sport Tourer (2016 year). Manual - part 5

1.66

ON-BOARD COMPUTER: trip settings

(3/6)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

On-board computer with mileage-

before-service message

c) Mileage before service or oil change.

Mileage before service

With the ignition switched on, and the engine not running

and the selected display is “Mileage before service”, press

button 2 or 3 for about 5 seconds to display the mileage before

service (distance or time to the next service). When the range

approaches its limit, there are several possible scenarios:

–

distance/time remaining less than 900 miles (1,500 km) or

one month: the message “Service due in” is displayed ac-

companied by the nearest term (distance or time);

–

distance equal to 0 miles or service date reached: the

message “service vehicle” is displayed accompanied by the

warning light.

The vehicle requires a service as soon as possible.

SERVICE

INTERVALS

Service in

30 000 Kms / 12 mo.

Service due in

300 Kms / 24 days

Service required

Resetting: to reset the distance before service, press and hold button 2 or 3 for approximately 10 seconds until the display

shows the service mileage without flashing.
NB: if a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the

event of an oil change, both the distance before the next service and the next oil change should be reset.

1.67

ON-BOARD COMPUTER: trip settings

(4/6)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

On-board computer with distance before

next service message (cntd.)

c) Mileage before service or oil change.

Mileage before service

With the ignition switched on and the engine not running,

and the selected display is “Mileage before service”, press

button 2 or 3 for about 5 seconds to display the mileage before

the next service, then briefly press button 2 or 3 to view the

mileage before the next oil change (distance or time remaining

before the next service). When the range approaches its limit,

there are several possible scenarios:

–

distance/time remaining less than 900 miles (1,500 km) or

one month: the message “Service due in” is displayed ac-

companied by the nearest term (distance or time);

–

range equal to 0 km/miles or service date reached: the

message “service vehicle” is displayed accompanied by the

warning light.

The vehicle requires an oil change as soon as possible.

SERVICE

INTERVALS

Oil change in

30 000 Kms / 24 mo.

Service due in

300 Kms / 24 days

Service required

Depending on the vehicle, the mileage before an oil change varies according to the driving style (frequent driving at low speed,

door-to-door journeys, extensive use at idling speed, towing a trailer, etc.). The distance remaining until the next oil change can

therefore decrease more quickly in some cases than the actual distance travelled.
Resetting: to reset the mileage before the next service, press and hold button 2 or 3 for approximately 10 seconds until the

display shows the mileage before service without flashing.

NB: if a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the

event of an oil change, both the distance before the next service and the next oil change should be reset.

1.68

ON-BOARD COMPUTER: trip settings

(5/6)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

d) Tyre pressure monitor

Refer to the information on the “Tyre pressure monitor”

in Section 2.

FRONT TYRES

2.2

REAR TYRES

2.2

1.69

ON-BOARD COMPUTER: trip settings

(6/6)

Examples of selections

Interpreting the display selected

e) Vehicle settings customisation menu.

Enables certain vehicle functions to be set (instrument panel language, parking

distance control, etc.). Refer to the information on “Vehicle settings customisation

menu” in Section 1.

Settings menu:

press and hold

f) Trip log.

Successive display:
–

information messages (passenger airbag OFF etc.),

–

operating fault messages (Check injection system, etc.).

No message available

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

1.70

TRIP COMPUTER AND WARNING SYSTEM: information messages

Examples of messages

Interpreting the display selected

«Battery low start

engine»

Indicates that the vehicle must be started to recharge the battery (eg. after the engine has been

switched off for some time whilst listening to the radio).

«Please remove

keycard»

Request to remove the RENAULT card from the reader when you leave the vehicle.

«Checking control

functions»

Displayed with the ignition on when the vehicle is running self-diagnostics.

«Traction control off»

Indicates that you have deactivated the traction control function.

«Turn steering

wheel + START»

Turn the steering wheel slightly whilst pressing the vehicle start button to unlock the steering

column.

«Auto Stop»

Indicates that the engine is on standby (related to the Stop and Start function – please see the in-

formation on “Stop and Start function” in Section 2).

«Steering wheel

not locked»

Indicates that the steering column has not been locked.

«Stop vehicle»

Indicates an electronic parking brake fault. Apply the electronic parking brake manually and ensure

that the vehicle is immobilised using a chock.

These can help in the vehicle starting phase, or give information about a selection or a driving status.

Examples of information messages are given in the following pages.

1.71

TRIP COMPUTER AND WARNING SYSTEM: operating fault messages

These appear with the

warning light and mean that you should drive very carefully to an authorised dealer as

soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle.
They disappear when the display selection key is pressed or after several seconds and are stored in the computer log. The

warning light stays on. Examples of operating fault messages are given in the following pages.

Examples of messages

Interpreting the display selected

«Clean diesel filter»

Indicates the presence of water in the diesel filter.

«Check lighting»

Indicates a fault in the directional headlights.

«Check vehicle»

Indicates a fault on one of the pedal sensors or in the battery management

system.

«Check airbag»

Indicates a fault in the restraint system in addition to the seat belts. In the event

of an accident, it is possible that they may not be triggered.

«Check anti-pollution system»

Indicates a fault in the vehicle’s particle filter system.

«Check injection»

Indicates an engine fault.

1.72

TRIP COMPUTER AND WARNING SYSTEM: warning message

These appear with the

warning light and require you to stop immediately, for your own safety, as soon as traffic

conditions allow. Stop your engine and do not restart it. Contact an approved Dealer.

Examples of warning messages are given in the following pages. Note: the messages appear on the display either individually

or alternately (when there are several messages to be displayed), and may be accompanied by a warning light and/or a beep.

Examples of messages

Interpreting the display selected

“Engine failure hazard”

Indicates engine overheating, or an injection or engine oil pressure fault.

“Power steering fault ” or

“Risk of steering locking ”

Indicates a fault in the steering.

“Parking brake fault”

Indicates an electronic parking brake fault. Apply the electronic parking brake manually

and ensure that the vehicle is immobilised using a chock.

“Battery charging fault”

Indicates a fault in the vehicle battery charging circuit (alternator etc.).

“Puncture”

Indicates a puncture on the tyre displayed on the instrument panel.

1.73

VEHICLE SETTINGS CUSTOMISATION MENU

i) Parking sensor volume;

j) Language.

function activated

function deactivated

Once a line has been selected, keep

pressing button 2 or 3 to change the

function. If you select either “Parking

sensor volume” or “Language”, you will

have to make a further selection (sound

volume of the parking distance control

or instrument panel language). In this

case, make your selection and confirm

it by holding either button 2 or 3, the

value selected is shown by a

front of the line.

To exit the menu, press either button 2

or 3. It may be necessary to carry out

this operation several times.

On equipped vehicles, this function,

which is integrated in the trip compu-

ter and warning system 1, allows you

to activate/deactivate some of the vehi-

cle’s functions.

Accessing the settings

customisation menu

With the vehicle stopped, press

button 2 or 3 several times until the

message “Settings menu: press and

hold” is shown on display 1. Press

either button 2 or 3 for longer than 2

seconds to enter the menu.

Adjusting the settings

Press one of buttons 2 or 3 to select a

function to change:

a) Auto door locking while driving;

b) Unlock driver’s door only;

c) Auto rear wipe with reverse gear;

d) Front parking sensor;

e) Automaticmain beam lights ;

f) Lane depart warn volume;

g) Lane depart warn sensitivity;

h) Rear parking sensor;

The vehicle settings personalisation

menu cannot be used when driv-

ing. At speed exceeding 12 mph

(20 km/h), the instrumental panel

display switches automatically back

to trip computer and warning system

mode.

1.74

The time and, depending on the vehi-

cle, the exterior temperature are dis-

played.

Resetting the clock 1

On equipped vehicles, buttons 2 and 3

are used to set the clock.
Press button 2 to adjust the hours and

button 3 to adjust the minutes.

External temperature

indicator
As ice formation is related

to climatic exposure, local

air humidity and temperature, the

external temperature alone is not

sufficient to detect ice.

CLOCK AND EXTERIOR TEMPERATURE

External temperature

indicator

Special note:
When the external temperature is be-

tween –3°C and +3°C, the °C charac-

ters flash (indicates risk of ice forma-

tion).

Vehicles equipped with a

navigation system, radio, etc.

For vehicles which are not fitted with

buttons 2 and 3, refer to the specific

equipment instructions to discover the

special features.

If the power supply is cut (battery

disconnected, supply wire cut, etc.),

the clock must be reset.
We recommend that you do not

adjust these settings while driving.

1.75

Folding door mirrors
The door mirrors automatically fold in

when the vehicle is locked (switch 2 in

position B). In this case, they will fold

out when the ignition is next switched

on.
In any case, you can make the door

mirrors fold in (switch 2 in position C) or

fold out (switch 2 in position A).
Automatic mode is then deactivated. To

reactivate it, position switch 2 to B.

REAR VIEW MIRRORS

Door mirrors

Adjustment
Select the door mirror using switch 3,

then use button 1 to adjust it to the de-

sired position.

Heated door mirrors
Mirror de-icing is carried out at the

same time as rear screen de-icing.

The driver’s door mirror

may have two clearly de-

fined zones. Zone E shows

what can normally be seen

in an ordinary rear view mirror.

Zone D increases rear side visibility.
Objects in the mirror are closer

than they appear.

Interior rear view mirror

Its position can be adjusted.

Rear view mirror with lever 4
When driving at night, to avoid being

dazzled by the headlights of the vehicle

behind, depress the little lever located

behind rear view mirror 4.

Rear view mirror without lever 4
The rear view mirror darkens automati-

cally at night if you are being followed

by a vehicle with its lights on.

1.76

AUDIBLE AND VISUAL SIGNALS

Horn

Press on the sides of the steering wheel

boss A.

Headlight flasher

Pull stalk 1 towards you to flash the

headlights.

Hazard warning lights

Press switch 2. This switch ac-

tivates all four direction indicators and

the side indicator lights simultaneously.

It must only be used in an emergency to

warn drivers of other vehicles that you

have had to stop in an area where stop-

ping is prohibited or unexpected or that

you are obliged to drive under special

conditions.
Depending on the vehicle, the hazard

warning lights may come on automati-

cally under heavy deceleration. You can

switch them off by pressing switch 2.

Direction indicators

Move stalk 1 parallel to the steering

wheel and in the direction you are going

to turn it.

One-touch mode
When driving, it is possible that the

steering wheel may not be turned suf-

ficiently to return the stalk automatically

to its starting position.

In this case, briefly turn stalk 1 to the in-

termediate position, then release it: the

stalk returns to its original point and the

indicator light flashes three times.

1.77

Daytime running lights

function

Depending on the vehicle, the daytime

running lights come on automatically

when the engine is started.

Main beam headlights

With the dipped beam head-

lights lit, pull stalk 1 towards you. This

indicator light on the instrument panel

comes on.
To return to the dipped headlight posi-

tion, pull stalk 1 towards you again.

Before driving at night,

check that the electrical

equipment is operating cor-

rectly and adjust the head-

light beams (if your vehicle is not

carrying its normal load). As a gen-

eral precaution, check that the lights

are not obscured (by dirt, mud,

snow or objects being transported).

EXTERIOR LIGHTING AND SIGNALS

(1/4)

Side lights

Turn the ring 2 until the symbol

is opposite mark 3. This indicator light

on the instrument panel comes on.

Dipped beam

headlights

Manual operation

Turn the ring 2 until the symbol is oppo-

site mark 3. This indicator light on the

instrument panel comes on.

Automatic operation

(depending on vehicle)

Turn ring 2 until the AUTO symbol is op-

posite mark 3: with the engine running,

the dipped beam headlights switch on

or off automatically depending on the

brightness of the light outside, without

any action on stalk 1.

If driving on the left in a left-hand

drive vehicle (or vice versa), drivers

must have the lights adjusted by an

authorised dealer for the duration of

the trip.

1.78

Automatic main beam

headlights

Depending on the vehicle, this system

switches the main beam headlights on

and off automatically. The function uses

a camera located behind the interior

rear-view mirror to detect vehicles that

are following and coming in the oppo-

site direction.
The main beam headlights come on au-

tomatically if:

– exterior light is weak;

– no other vehicles or lighting are de-

tected;

– the vehicle speed is above approxi-

mately 30 mph (45 km/h).

If any of the above conditions are not

fulfilled, the system switches to dipped

beam headlights.

The “automatic main beam headlights” system should under no circum-

stances be used to replace driver attention and responsibility with regard

to vehicle lighting and adapting to light, visibility and traffic conditions.

Using the portable naviga-

tion system at night in the

windscreen area below the

camera may disturb the op-

eration of the “automatic main beam

headlights” system (risk of reflection

on the windscreen).

Activation
Turn ring 2 until the AUTO symbol is op-

posite mark 3.

Pull stalk 1 to activate main beam

headlights.

Warning light

comes on the in-

strument panel.

Deactivation
– pull stalk 1 again;

– turn ring 2 to a position other than

AUTO.

Warning light

goes out on the in-

strument panel.

EXTERIOR LIGHTING AND SIGNALS

(2/4)

Turning on the fog lights deactivates

the system and prevents it from

being activated.

The system may encounter difficul-

ties under certain conditions, includ-

ing:
– extreme weather conditions (rain,

snow, fog, etc.);

– obstruction in front of the wind-

screen or camera;

– when a following or oncoming ve-

hicle has weak or hidden lighting;

– incorrect settings for the front

headlights;

– reflecting systems.

1.79

EXTERIOR LIGHTING AND SIGNALS

(3/4)

Special note:

– If the dipped beam headlights are

manually switched on and if the light

is sufficient, the directional head-

lights will remain fixed;

– If the lights come on automatically

when cornering, the directional

headlights will start working from the

next time the vehicle corners;

– When the dipped beam headlights

are switched on with the engine

running and the vehicle stationary,

the lights move to reinitialise them-

selves. If not, there is a system fault.

Switching off the lights

There are two possibilities:

– manually, move ring 2 to position 0;

– automatically, the lights will go out

when the engine is switched off, the

driver’s door is opened or the vehicle

is locked. In this case, the next time

the engine is started the lights will be

switched back on according to the

position of the ring 2.

NB: if the fog lights are lit, the lights are

not switched off automatically.

“See-me-home lighting”

function

This function allows you to briefly switch

on the dipped beam headlights (to pro-

vide light when opening a gate, etc.).
With the engine and lights off and

the ring 2 in the position 0, pull stalk 1

towards you: the dipped beam head-

lights come on for approximately thirty

seconds. To increase this duration, you

may pull the stalk up to four times (total

time restricted to two minutes). The

message “See-me-home” along with

the times the lights will be on for is dis-

played on the instrument panel to con-

firm this action.
To switch off the lights before they go

out automatically, turn ring 2 to any po-

sition, then return it to position 0.

Directional headlights

Depending on the vehicle, with the

dipped beam headlights on and under

certain conditions (speed, steering

wheel angle, forwards gear selected,

etc.) when cornering, the dipped beam

headlights move to light the inside of

the bend.
Operating faults
Depending on the vehicle, when the

message “Check lighting” appears on

the instrument panel along with the

warning light, this indicates that

there is a lighting fault.

Consult an approved dealer.

1.80

EXTERIOR LIGHTING AND SIGNALS

(4/4)

When driving in fog or snow, or

when transporting objects which are

higher than the roof, the headlights

do not come on automatically.
Switching on the fog lights remains

the responsibility of the driver: the

indicator lights on the instrument

panel inform you whether the fog

lights are lit (indicator light on) or not

(indicator light not on).

Front fog lights

Turn centre ring 5 on stalk 1

until the symbol faces mark 6, then re-

lease it.
Operation of the fog lights depends on

the exterior lighting position selected,

and an indicator light will light up on the

instrument panel.

Rear fog light

Turn centre ring 5 on the stalk

until the symbol faces mark 6, then re-

lease it.
Operation of the fog lights depends on

the exterior lighting selected, and an in-

dicator light will light up on the instru-

ment panel.
To avoid inconveniencing other road

users, remember to switch off the rear

fog light when it is no longer needed.

Lights-on reminder buzzer

If the lights are on after the engine is

switched off, a warning beep sounds

when the driver’s door is opened to

warn you that the lights are still on.

Switching off the lights

Turn ring 5 again until mark 6 is oppo-

site the symbol for the fog light that you

wish to switch off. The corresponding

indicator light on the instrument panel

goes out.
The front and rear fog lights switch off

when the exterior lights are switched

off.

1.81

On vehicles fitted with this function,

control A allows you to adjust the height

of the beams according to the load.

Turn control A downwards to lower the

headlights and upwards to raise them.

For vehicles not fitted with control A,

adjustment is automatic.

ADJUSTING THE HEADLIGHT BEAM HEIGHT

Examples of positions for adjusting

control A according to the load

Five door

Three door

Driver alone or with front

passenger

Driver with one front

passenger and one rear

passenger

Driver with one front

passenger and two or three

rear passengers

Driver with one front

passenger, three rear

passengers and luggage

If driving on the left in a left-hand

drive vehicle (or vice versa), drivers

must have the lights adjusted by an

authorised dealer for the duration of

the trip.

Content .. 3 4 5 6 ..
